Frame Assembly Parts Breakdown

Model # SP-1575

BOM ID Description Qty

1

D5102

1

2

D5103

1

3

D5107

1

4

D5120

1

5

D5138

1

6

D5139

1

7

D5140

1

BOM ID Description Qty
8

D5535

4

9

D6107

1

10

D6131

4

11

D6132

4

12

D6165

1

13

D6172

4

14

D6214

2

BOM ID Description Qty
15

D6232

2

16

D6327

1

17

D6332

1

18

D6333

6

19

D6452

2

20

D6467

6

21

D6566

1

BOM ID Description Qty

22

D6584

4

23

D6651

2

24

D6746

1

25

D6750

1

26

D6781

2

27

D6874

1
