Harness diagram – SnowEx SP-1875 User Manual
Page 13
13
© Trynex International 2011 (REV A) F50872
Harness Diagram
Model # SP-1575/SP-1875
Spinner Red
Vibrator
Auger
Spinner
Auger Red
Vibrator Red
Black
Black
Black
Red Leads Female
Black Leads Male
D6321 Spreader Harness
D6527 Controller
Black
Negative (-)
Red
Positive (+)
Vibrator
Red Positive (+)
Spinner
Red Positive (+)
Auger
Red Positive (+)
Vibrator
Black Negative (-)
Spinner
Black Negative (-)
Auger
Black Negative (-)
