Frame assembly overview – ShelterLogic 29770 12 x 26 Super Max Canopy User Manual
Page 3
05-25770-0D
Page 3
Quantity
Part #
Rafter Poles 34.9" / 88,6 cm
10
800241
Upright Pole 39.4" / 100,1 cm
Upright Pole 39.4" / 100,1 cm
Top Cross Rail 40" / 101,6 cm
Top Cross Rail 38.2" / 97 cm
10
10
12
12
800243
10093
10161
800242
(Top/Center, shallow bend)
3-Way Frame Connectors
(Side/Corner, sharper bend)
3-Way Frame Connectors
Short Pins/Rings 2
1
/
4
x 1/4"
Long Pins/Rings 2
7
/
8
" x 1/4"
2
4
6
10046
10045
10051
White Cover
Plastic Foot Plates
10
10050
White Bungee Cords
32
10066
Swedged Rafter Pole 34.9" / 88,6 cm
10
800240
4-Way Frame Connectors
4-Way Frame Connectors
3
6
10
10048
10047
10052
1
10059
Description of Parts:
TwistTite™ set (Bungees + "S" hooks)
4
10056
Anchor
10
10431
12' x 26' SuperMax Canopy - 10 Leg - Parts List - Model #25770
FRAME ASSEMBlY OVERVIEW
01 10046
02 10048
03 10045
04 10047
05 800240
06 800241
07 800243
08 10093
09 10161
10 800242
