Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most
Warren Rupp distributors. The pump
owner may prefer to maintain a limited
inventory of these parts in his own stock to
reduce repair downtime to a minimum.

IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.

Model PB1½-A & PB2-A

Page 7

520-130-000

2/97

MATERIAL CODES

The Last 3 Digits of Part Number

000... Assembly, sub-assembly; and some

purchased items

010... Cast Iron
015... Ductile Iron
025... Music Wire
080... Carbon Steel, AISI B-1112
110... Alloy Type 316 Stainless Steel
112... Alloy “C”
114... 303 Stainless Steel
115... 301/302/304 Stainless Steel
120... 416 Stainless Steel (Wrought Martensitic)
148... Hardcoat Anodized Aluminum
150... 6061-T6 Aluminum
151... 6063-T6 Aluminum
154... Almag 35 Aluminum
155 or 156...356-T6 Aluminum
157... Die Cast Aluminum Alloy #380
159... Anodized Aluminum
162... Brass, Yellow, Screw Machine Stock
170... Bronze, Bearing Type, Oil Impregnated
180... Copper Alloy
330... Plated Steel
331... Chrome Plated Steel
332... Electroless Nickel Plated
335... Galvanized Steel
354... Injection Molded #203-40 Santoprene —

Duro 40D +/-5; Color: RED

356... Hytrel
357... Rupplon (Urethane Rubber)
360... Buna-N Rubber. Color coded: RED
363... Viton (Fluorel). Color coded: YELLOW
364... E.P.D.M. Rubber. Color coded: BLUE
365... Neoprene Rubber. Color coded: GREEN
366... Food Grade Nitrile. Color coded: WHITE
375... Fluorinated Nitrile
405... Cellulose Fibre
408... Cork and Neoprene
425... Compressed Fibre
440... Vegetable Fibre
500... Delrin 500
501... Delrin 570
520... Injection Molded PVDF, Natural Color,

Food Grade/USDA Acceptable

540... Nylon
550... Polyethylene
551... Polypropylene
555... PVC (Polyvinyl Chloride)
580... Ryton
600... Teflon (virgin material) Tetrafluoroethylene (TFE)
603... Blue Gylon
604... Teflon — Diaphragm
610... Encapsulated Silicon
611... Teflon Encapsulated Viton

Delrin, Teflon, Hytrel, and Viton are
registered tradenames of E.I. DuPont.

Gylon is a registered tradename of Garlock, Inc.

Rupplon and SandPIPER are registered
tradenames of Warren Rupp, Inc.

Ryton is a registered tradename of Phillips
Chemical Company.

Loctite is a registered tradename of Loctite Corporation.

ITEM

TOTAL

NO.

PART NUMBER

DESCRIPTION

RQD.

37

612-086-551

Plate, Outer Diaphragm

2

(includes item #51, Stud)

612-086-520

Plate, Outer Diaphragm

2

38

196-045-551

Chamber, Outer

2

196-045-520

Chamber, Outer

2

39

670-030-551

Retainer, Ball

4

670-030-520

Retainer, Ball

4

40

722-039-551

Seat, Ball

4

722-039-520

Seat, Ball

4

41

050-005-365

Ball, Check Valve

4

050-010-600

Ball, Check Valve

4

050-005-360

Ball, Check Valve

4

050-005-363

Ball, Check Valve

4

050-005-364

Ball, Check Valve

4

42

560-061-611

O-Ring (Polypro. only)

8

560-061-360

O-Ring (Polypro. only)

8

560-089-611

O-Ring (PVDF only)

8

43

312-036-551

Elbow, Suction

2

312-036-520

Elbow, Suction

2

44

312-035-551

Elbow, Discharge

2

312-035-520

Elbow, Discharge

2

45

518-031-551

Manifold (PB1½)

2

518-031-520

Manifold (PB1½)

2

518-088-520

Manifold (PB2)

2

46

560-060-611

O-Ring

4

560-047-360

O-Ring

4

47

200-019-115

Clamp, V-Band Assembly

2

48

200-020-115

Clamp, V-Band Assembly

4

49

200-021-115

Clamp, V-Band Assembly

4

50

901-001-330

Washer, Flat

6

51

807-026-330

Stud

2

52

530-008-000

Muffler

1

53

312-044-555

Elbow, 45

o

1

54

171-025-332

Capscrew

4

55

545-005-115

Hex Nut

4

56

171-045-332

Carriage Bolt

16

57

545-004-115

Hex Nut

16

60

132-022-360

Bumper

2

61

360-071-600

Gasket (Polypro. only)

8

62

360-072-600

Gasket (Polypro. only)

4

63

360-073-600

Gasket (Polypro. only)

2

NOT SHOWN:

535-015-000

Name Plate

1

535-019-115

Name Plate

2

710-010-115

Self-Tapping Screw

8

031-031-000

Valve Body Assembly

1

(includes items 9, 13, 14, 15, 16)
