Models DA05, DA07, DA10 Page 4
da050710sdsm-rev0811
ITEM PART
TOTAL
NO.
NUMBER
DESCRIPTION
RQD.
1
196-161-552 Chamber, Outer
1
196-161-520 Chamber, Outer
1
196-161-542 Chamber, Outer
1
196-171-110 Chamber, Outer (DA05 Metallic only)
1
196-171-157 Chamber, Outer (DA05 Metallic only)
1
2
360-099-360 Gasket, Spacer
1
3
334-103-552 Flange, Threaded ½" NPT (DA05)
2
334-103-542 Flange, Threaded ½" NPT (DA05)
2
334-103-600 Flange, Threaded ½" NPT (DA05)
2
334-109-110 Flange, Threaded ½" NPT (Metallic DA05 only)
2
334-109-150 Flange, Threaded ½" NPT (Metallic DA05 only)
2
334-104-552 Flange, Threaded ¾" NPT (DA07)
2
334-104-542 Flange, Threaded ¾" NPT (DA07)
2
334-104-600 Flange, Threaded ¾" NPT (DA07)
2
334-107-552 Flange, 1" ANSI (DA10)
2
4
135-022-115 Bushing, Reducer
2
5
196-166-552 Chamber, Inner
1
6
720-058-600 Seal, Flange
2
720-063-600 Seal, Flange (Metallic DA05 only)
2
7
286-097-600 Diaphragm
1
8
171-064-115 Capscrew Hex Flange 5/16 -18 x 1.50
4
171-064-308 Capscrew Hex Flange 5/16 -18 x 1.50
4
170-029-330 Capscrew, Hex Flange x 1.25 (Metallic DA05 only)
4
9
544-005-115 Nut 5/16 Hex Flange Nut 5/16-18
10
544-005-308 Nut 5/16 Hex Flange Nut 5/16-18
10
545.004-330 Hex Flange Nut (Metallic DA05 only)
10
10
171-070-115 Capscrew Hex Flange 5/16 -18 x 3.00
6
171-070-308 Capscrew Hex Flange 5/16 -18 x 3.00
6
171-070-330 Capscrew, Hex Flange (Metallic DA05 only)
2
11
171-069-115 Capscrew Hex Flange 5/16 -18 x 2.5
2
171-069-308 Capscrew Hex Flange 5/16 -18 x 2.5
2
171-069-330 Capscrew, Hex Flange (Metallic DA05 only)
2
12
538-002-115 Nipple 1/8 NPT
1
13
020-039-000 Regulator W/Gauge
1
14
171-063-115 Capscrew Hex Flange 5/16 -18 x 1.50
4
171-063-308 Capscrew Hex Flange 5/16 -18 x 1.50
4
170-045-330 Capscrew Hex Flange 5/16 -18 x 1.25
4
15
900-004-330 LockWasher (DA05 Metallic Only)
14
16
901-038-115 Flat Washer (Non-Metallic Only)
2
Repair Parts shown in
bold face (darker)
type are more likely to need replacement
after extended periods of normal use. They
are readily available from most Warren Rupp,
Inc.
distributors. The pump owner may prefer
to maintain a limited inventory of these parts
in his own stock to reduce repair downtime
to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
000... Assembly, sub-assembly; and some
purchased items
110... CF*M (316) Stainless Steel
115... 302/304 Stainless Steel
157... 380/383 Die Cast Aluminum
308... Stainless Steel; Black PTFE Coated
330... Zinc Plated Carbon Steel
360... Nitrile Rubber. Color coded: RED
520... Injection Molded PVDF, Natural Color,
542... Nylon
552... Polypropylene
600... Virgin PTFE
©Copyright 2011 Warren Rupp, Inc. All rights reserved.
Model DA05 ½" Surge Dampener
Model DA07 ¾" Surge Dampener
Model DA10 1" Surge Dampener
REPAIR PARTS LIST
