SANDPIPER MP05D - Manual (Page 2)

Model MP05D Design Level 1 Page 2 520-168-000 3/03
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD.
36 286-008-365 Diaphragm 2
286-008-363 Diaphragm 2
286-008-360 Diaphragm 2
286-008-364 Diaphragm 2
286-008-354 Diaphragm 2
37 722-045-365 Seat, Valve 4
722-045-360 Seat, Valve 4
722-045-600 Seat, Valve 4
38 050-019-365 Ball, Check Valve 4
050-019-360 Ball, Check Valve 4
050-024-600 Ball, Check Valve 4
39 518-122-156 Manifold, Suction 1
40 518-121-156 Manifold, Discharge 1
41 170-029-330 Capscrew. Hex Head 12
42 901-039-330 Washer, Flat 12
43 545-004-330 Nut, Hex 16
44 618-003-330 Pipe, Plug 1
45 618-003-330 Pipe Plug 2
46 196-057-156 Chamber, Outer 2
47 530-018-000 Muffler, Exhaust 1
48 312-044-555 45° Elbow 1
49 538-025-555 Nipple, Close 1
50 132-022-360 Bumper 2
51 286-066-365 Diaphragm 2
286-066-360 Diaphragm 2
286-066-363 Diaphragm 2
286-066-364 Diaphragm 2
286-066-354 Diaphragm 2
286-040-604 Diaphragm 2
52 538-083-115 Nipple, Pipe 4
53 835-005-115 Tee, Pipe 4
54 618-003-110 Plug, Pipe 4
55 866-060-115 Fitting, Male 4
56 860-054-606 Tube, Sight 2
57 170-099-330 Capscrew, Hex Head 16
58 618-025-110 Boss Plug and O-Ring 2
59 286-015-604 Diaphragm, PTFE (Overlay) 2
69 132-028-552 Bumper, Spool 2
71 210-008-330 Clip, Safety 1
72 560-029-360 O-Ring 2
Not Shown:
031-111-000 Valve Body Assy. 1
(Consists of items 1, 2, 3, 4, 5,
69, 71 & 72)
Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most
MARATHON distributors. The pump
owner may prefer to maintain a limited
inventory of these parts in his own stock
to reduce repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
Continued from previous page
375…Fluorinated Nitrile
378…High density Polypropylene
405…Cellulose Fibre
408…Cork and Neoprene
425…Compressed Fibre
426…Blue Gard
440…Vegetable Fibre
465…Fibre
500…Delrin 500
501…Delrin 570
505…Acrylic Resin Plastic
520…Injection Molded PVDF Natural Color
540…Nylon
541…Nylon
542…Nylon
544…Nylon Injection Molded
550…Polyethylene
551…Polypropylene
552…Unfilled Polypropylene
553…Unfilled Polypropylene
555…Polyvinyl Chloride
570…Rulon II
580…Ryton
590…Valox
591…Nylatron G-S
592…Nylatron NSB
600…PTFE (virgin material) Tetrafluoroethylene (TFE)
601…PTFE (Bronze and moly filled)
602…Filled PTFE
603…Blue Gylon
604…PTFE
606…PTFE
610…PTFE Encapsulated Silicon
611…PTFE Encapsulated Viton
Delrin, PTFE, Viton and Hytrel are registered
tradenames of E.I. DuPont.
Gylon is a registered tradename of Garlock. Inc.
Nylatron is a registered tradename of Polymer Corp.
Rulon II is a registered tradename of Dixion Industries
Corporation.
Hastelloy-C is a registered tradename of Cabot Corp.
Ryton is a registered tradename of Phillips Chemical
Company.
Valox is a registered tradename of General Electric
Company.
