Model MP14D Design Level 1 Page 2 520-171-000 3/03
ITEM TOTAL
NO. PART NUMBER DESCRIPTION RQD. Repair Parts shown in bold face (darker)
type are more likely to need replacement
after extended periods of normal use.
They are readily available from most
MARATHON distributors. The pump owner
may prefer to maintain a limited inventory
of these parts in his own stock to reduce
repair downtime to a minimum.
IMPORTANT: When ordering repair parts
always furnish pump model number, serial
number and type number.
MATERIAL CODES
The Last 3 Digits of Part Number
Continued from previous page
375…Fluorinated Nitrile
378…High density Polypropylene
405…Cellulose Fibre
408…Cork and Neoprene
425…Compressed Fibre
426…Blue Gard
440…Vegetable Fibre
465…Fibre
500…Delrin 500
501…Delrin 570
505…Acrylic Resin Plastic
520…Injection Molded PVDF Natural Color
540…Nylon
541…Nylon
542…Nylon
544…Nylon Injection Molded
550…Polyethylene
551…Polypropylene
552…Unfilled Polypropylene
553…Unfilled Polypropylene
555…Polyvinyl Chloride
570…Rulon II
580…Ryton
590…Valox
591…Nylatron G-S
592…Nylatron NSB
600…PTFE (virgin material) Tetrafluoroethylene (TFE)
601…PTFE (Bronze and moly filled)
602…Filled PTFE
603…Blue Gylon
604…PTFE
606…PTFE
610…PTFE Encapsulated Silicon
611…PTFE Encapsulated Viton
Delrin, PTFE, Viton and Hytrel are registered
tradenames of E.I. DuPont.
Gylon is a registered tradename of Garlock. Inc.
Nylatron is a registered tradename of Polymer Corp.
Rulon II is a registered tradename of Dixion Industries
Corporation.
Hastelloy-C is a registered tradename of Cabot Corp.
Ryton is a registered tradename of Phillips Chemical
Company.
Valox is a registered tradename of General Electric
Company.
050-014-360 Ball, Check Valve 4
050-015-600 Ball, Check Valve 4
36 518-123-156 Manifold, Suction (AL) 1
518-123-110 Manifold, Suction (SS) 1
37 518-124-156 Manifold, Discharge (AL) 1
518-124-110 Manifold, Discharge (SS) 1
38 170-055-330 Capscrew, Hex Head 12
39 326-002-080 Mounting Foot 2
40 286-067-354 Diaphragm 2
286-067-365 Diaphragm 2
286-067-360 Diaphragm 2
286-067-363 Diaphragm 2
286-067-364 Diaphragm 2
286-068-604 Diaphragm 2
41 170-034-330 Capscrew, Hex Head 12
42 807-046-330 Stud 2
43 196-052-156 Chamber, Outer (AL) 2
196-052-110 Chamber, Outer (SS) 2
44 612-090-156 Plate, Outer Diaphragm Assembly 2
52 170-102-330 Capscrew, Hex Head (AL only) 16
170-102-115 Capscrew, Hex Head (SS only) 12
53 196-136-156 Chamber, Driver 2
196-141-156 Chamber, Driver (AL,w/PTFE overlay) 2
196-141-110 Chamber, Driver (SS,w/PTFE overlay) 2
54 426-042-000 Hose Assembly 2
55 866-059-115 Fitting, Male 4
56 618-003-110 Plug, Pipe 4
57 835-005-115 Tee, Pipe 4
58 538-083-115 Nipple, Pipe 4
60 618-025-115 Boss Plug and O-Ring 2
61 210-008-330 Clip, Safety 1
62 866-060-110 Connector (SS only) 4
63 860-047-606 Tube, Sight 2
64 807-042-115 Stud 8
65 560-023-360 O-Ring, End Cap 2
66 612-139-010 Plate, Spacer 1
Not Shown:
031-090-156 Main Air Valve Assembly (AL) 1
(Includes Items 9, 10, 11, 13, 14,
15, 16 & 61)
031-090-010 Main Air Valve Assembly (SS) 1
(Includes Items 9, 10, 11, 13, 14,
15, 16 & 61)
* Item 6 is available in kit form. Order P/N 031-055-000 which also includes
Items 5, 7, 12, & 20.
