SANDPIPER M20 Non-Metallic - Manual (Page 15)

m20nmdl3sm-rev0713 Model M20 Non-Metallic Page 13
20 312-116-520 Elbow, Suction 2
312-116-552 Elbow, Suction 2
312-116-557 Elbow, Suction 2
21 360-093-360 Gasket, Main Air Valve 1
22 360-103-360 Gasket, Pilot Valve 1
23 360-104-360 Gasket, Air Inlet Cap 1
360-104-379 Gasket, Air Inlet Cap (Conductive Models Only) 1
24 360-107-360 Gasket, Inner Chamber 2
25 518-199-520 Manifold 2
518-199-520E Manifold, 50mm DIN 2
518-199-552 Manifold 2
518-199-552E Manifold, 50mm DIN 2
518-199-557 Manifold 2
518-199-557E Manifold, 50mm DIN 2
26 545-008-110 Nut, Hex 1/2-13 24
545-008-308 Nut, Hex 1/2-13 24
27 545-009-110 Nut, Hex 5/8-11 1
545-009-308 Nut, Hex 5/8-11 16
28 560-001-360 O-Ring 2
29 612-195-157 Inner Diaphragm Plate 2
612-227-150 Inner Diaphragm Plate (One-Piece Bonded Option ) 2
30 612-225-520 Outer, Plate Diaphragm 2
612-225-552 Outer, Plate Diaphragm 2
31 620-004-114 Plunger, Actuator 2
32 670-046-520 Retainer, Ball 4
670-046-552 Retainer, Ball 4
33 675-042-115 Ring, Retainer 2
34 685-063-120 Rod Diaphragm 1
35 720-004-360 Seal, U-Cup 2
36 720-038-600 Seal, Manifold 4
37 720-041-600 Seal, Check Valve Assembly 8
38 722-075-520 Seat, Check Valve 4
722-075-552 Seat, Check Valve 4
39 901-038-115 Washer, Flat 5/16" 4
901-038-308 Washer, Flat 5/16" 4
40 901-046-115 Washer, Flat 1/2" 48
901-046-308 Washer, Flat 1/2" 48
41 901-047-115 Washer, Flat 5/8" 32
901-047-308 Washer, Flat 5/8" 32
42 901-048-115 Washer, Flat 3/8" 4
901-048-308 Washer, Flat 3/8" 4
NOT SHOWN:
535-010-000 Muffler 1
530-027-000 Muffler 1
530-033-000 Muffler 1
ITEM PART NUMBER DESCRIPTION QTY
1 031-140-000 Air Valve Assembly 1
031-140-001 Air Valve Assembly
031-140-002 Air Valve Assembly w/ PTFE coated Hardware 1
031-141-000 Air Valve Assembly (No Integral Muffler) 1
031-141-001 Air Valve Assembly (No Integral Muffler) 1
031-141-002 Air Valve Assembly (No Integral Muffler 1
PTFE Coated Hardware)
2 095-110-558 Pilot Valve Assembly 1
3 050-038-354 Ball, Check 4
050-038-360 Ball, Check 4
050-038-365 Ball, Check 4
050-038-600 Ball, Check 4
4 114-024-551 Intermediate Assembly 1
114-024-559 Intermediate Assembly 1
5 132-035-360 Bumper Diaphragm 2
6 135-034-506 Bushing, Plunger 2
7 165-116-551 Air Inlet Cap Assembly 1
165-116-559 Air Inlet Cap Assembly 1
8 170-055-115 Capscrew, Hex HD 1/2-13 x 2.50 16
170-055-308 Capscrew, Hex HD 1/2-13 x 2.50 16
9 170-066-115 Capscrew, Hex HD 1/2-13 x 2.25 8
170-066-308 Capscrew, Hex HD 1/2-13 x 2.25 8
10 170-069-115 Capscrew, Hex HD5/16-18 x 1.75 4
170-069-308 Capscrew, Hex HD 5/16-18x 1.75 4
11 170-092-115 Capscrew, Hex HD 1/2-13 x 4.00 8
170-092-308 Capscrew, Hex HD 1/2-13 x 4.00 8
12 170-015-115 Capscrew, Hex HD 5/8-11 x 2.75 16
170-015-308 Capscrew, Hex HD 5/8-11-x 2.75 16
13 171-053-115 Capscrew, Soc HD 3/8-16 X 2.75 4
171-053-308 Capscrew, Soc HD 3/8-16X 2.75 4
14 171-078-115 Capscrew, Flat HD 3/8-16 X1.25 8
15 196-188-551 Chamber, Inner 2
196-188-559 Chamber, Inner 2
16 196-190-520 Chamber, Outer 2
196-190-552 Chamber, Outer 2
196-190-557 Chamber, Outer 2
17 286-005-354 Diaphragm 2
286-005-360 Diaphragm 2
286-005-363 Diaphragm 2
286-005-365 Diaphragm 2
286-114-000 Diaphragm, One-Piece Bonded PTFE 2
18 286-119-600 Diaphragm, Overlay 2
19 312-102-520 Elbow, Discharge 2
312-102-552 Elbow, Discharge 2
312-102-557 Elbow, Discharge 2
ITEM PART NUMBER DESCRIPTION QTY
Composite Repair Parts List
Note: ATEX Compliant
