SANDPIPER WR10 3/8 - Manual (Page 8)

Page 5 Rev 0614
WR10 PARTS LIST
AIR VALVE ASSEMBLY
Item Description Qty. Standard: Polypropylene
Air Valve Assembly (Includes items 1-10) 1 E800
1 Valve Body 1 10-048
2 Valve Spool 1 E500B ASY (Includes (2) P98-104A)
3 Valve Spool U-Cup 2 P98-104A
4 End Cap 2 E800D (Includes (1) E800D ASY)
5 End Cap O-Ring 2 E500E
8 Air Diverter 1 10-075
9 Valve Insert 1 E500H
10 Valve Gasket 1 E800J
11 Valve Screw 4 10-050
Item Description Qty. Standard: Polypropylene
12 Center Section 1 E801A
18 Pilot Shaft 1 E803A
19 Pilot Shaft Spacer 5 E503C
20 Pilot Shaft O-Ring 6 E503B
21 Pilot Shaft Snap Ring 2 E503D
22 Shaft Retainer 2 E801B
25 Shaft Retainer Screw 4 E501C
33 Muffler 1 06-034
Item Description Qty. TPE PTFE
34 Main Shaft O-Ring 2 E503B E503B
35 Main Shaft 1 10-028 10-028
37 Inner Diaphragm Plate 2 C126 C126
38 Outer Diaphragm Plate 2 10-023 (Poly), 10-040 (Kynar) 10-023 (Poly), 10-040 (Kynar)
40 Diaphragm 2 10-032 (XL), 10-033 (Geolast) 10-044 (PTFE)
Item Description Qty. Standard: Polypropylene Option 1: Kynar
44 Water Chamber 2 10-002 10-036
45 Water Chamber Bolt (Long) 4 10-052 10-052
46 Water Chamber Bolt (Short) 12 10-051 10-051
50 Valve Seat 4 10-022 (Poly) 10-039 (Kynar)
51 Valve Seat Seal 8 10-073 (XL), 10-045 (PTFE) 10-073 (XL), 10-045 (PTFE)
52 Valve Stem 4 10-005 10-038
53 Spring 4 10-030 10-030
60 Manifold 2 10-003 10-037
62 Foot Pad 4 10-035 10-035
AIR END ASSEMBLY
DIAPHRAGM ASSEMBLY
WET END ASSEMBLY
