Dimensional drawings, T15 metallic, Pump specs – SANDPIPER T15 User Manual
Page 6
t15mdl1sm-rev0614
sandpiperpump
.
com
3
• Model T15 Metallic
T15 Metallic
The dimensions on this drawing are for reference only. A certified drawing can be requested if physical dimensions are needed.
Dimensional Drawings
Dimensions in Millimeters
Dimensional Tolerance:± 3mm
Dimensions in Inches
Dimensional Tolerance:±
1
/
8
"
Dimension
A
B
C
D
E
20 3/8
518
1 31/32
50
3/8
10
11 3/8
289
Stainless
Steel
Metal
Muffler
14 1/2
368
F
21 21/32
550
66
1: PUMP
SPECS
