Model T15 Metallic •
8
Composite Repair Parts List
LEGEND:
= Items contained within Air End Kits
= Items contianed within Wet End Kits
Note: Kits contain components specific to the material codes.
Item
Part Number
Description
Qty
1
031.183.313
Air Valve Assembly
1
031.179.000
Air Valve Assembly
1
(ATEX compliant w/Cast Iron centers only)
2
050.005.351
Ball, Check
4
050.010.600
Ball, Check
4
3
070.006.170
Bushing
2
4
095.110.313
Pilot Valve Assembly
1
095.110.110
Pilot Valve Assembly
(use w/Cast Iron centers only)
1
5
114.024.313
Intermediate Bracket
1
114.024.110
Intermediate Bracket
1
6
132.035.360
Bumper, Diaphragm
2
7
135.034.506
Bushing, Plunger
2
8
165.118.313
Cap, Air Inlet Assembly
1
165.118.110
Cap, Air Inlet Assembly
1
9
170.060.115
Capscrew, Hex Hd 7/16-14 X 2.00
16
10
170.061.115
Capscrew, Hex Hd 3/8-16 X 1.75
16
11
170.069.115
Capscrew, Hex Hd 5/16-18 X 1.75
4
12
170.006.115
Capscrew, Hex HD 3/8-16 X 1.00
4
171.053.115 Capscrew, Soc Hd 3/8-16 X 2.50
(Stroke Indicator Only)
4
13
171.059.115
Capscrew, Soc Hd 7/16-14 X 1.25
8
171.011.115
Capscrew, Soc Hd 1/2-13 X 1.00
(Stainless Center)
8
14
196.169.110
Chamber, Outer
2
15
196.170.313
Chamber, Inner
2
196.170.110
Chamber, Inner
2
16
286.099.351
Diaphragm
2
17
286.099.600
Diaphragm, Overlay
2
18
360.093.360
Gasket, Air Valve
1
19
360.103.360
Gasket, Pilot Valve
1
Item
Part Number
Description
Qty
20
360.104.379
Gasket, Air Inlet
1
21
360.105.360
Gasket, Inner Chamber
2
22
518.151.110TC
Manifold, Suction
1
23
518.152.110TC
Manifold, Discharge
1
24
545.005.115
Nut, Hex 3/8-16
16
25
545.007.115
Nut, Hex 7/16-14
16
26
560.001.379
O.Ring
2
27
560.084.611
Seal (O.Ring) (See item 34)
8
720.061.608
Seal (O.Ring) (See item 34)
8
28
612.097.110
Plate, Outer Diaphragm Assembly
2
29
612.195.157
Plate, Inner Diaphragm
2
30
620.020.115
Plunger, Actuator
2
31
675.042.115
Ring, Retaining
2
32
685.059.120
Rod, Diaphragm
1
33
720.004.360
Seal, Diaphragm Rod
2
34
722.091.110
Seat, Check Ball
(seals required see item 27)
4
35
901.038.115
Washer, Flat 5/16
4
36
901.048.115
Washer, Flat 3/8 (Stroke Indicator Only) 4
43
530.033.000
Metal Muffler
(for other muffler options see pg. 24)
1
Parts Not Shown (For Rubber Mounting Feet)
350.001.360
Foot, Rubber
4
170.018.115
Capscrew, Hex HD
4
545.005.115
Nut, Hex
4
900.005.115
Washer, Lock
4
901.005.115
Washer, Flat
8
3: EXP
VIEW
