Model HDB1½/HDB40 •
10
hdb15dl7sm-rev0714
Composite Repair Parts List
Item Part Number Description
Qty.
25
360.041.379
Gasket, Pilot Valve
1
26
360.048.425
Gasket, Air Valve
1
27 518.003.156 Manifold
1
518.003.010 Manifold
1
518.003.110 Manifold
1
518.003.112 Manifold
1
28
530.036.000
Muffler
1
29
545.005.330
Nut, Hex, 3/8-16
6
30
545.007.330
Nut, Hex, 7/16-14 (Side Ported Units)
16
545.007.330
Nut, Hex 7/16-14 (Down Ported Units)
20
31
560.001.360
O-Ring (Sold with Item 39)
2
32 560.022.360 O-Ring
2
33 560.028.360 O-Ring
2
560.028.610
O-Ring (PTFE and FKM Fitted Units Only)
2
34
570.009.360
Pad, Wear
2
570.009.363
Pad, Wear
2
570.009.364
Pad, Wear (Also used with
Santoprene (354) Fitted Units)
2
570.009.365
Pad, Wear
2
35
612.052.157
Plate, Inner Diaphragm
2
612.052.010
Plate, Inner Diaphragm
2
612.219.150
Plate, Inner Diaphragm
(Used with 286.114.654
One-Piece Bonded PTFE Diaphragm)
2
36
612.039.157
Plate, Outer Diaphragm Assy.
(Not Used with 286.114.000)
2
612.039.010
Plate, Outer Diaphragm Assy.
(Not Used with 286.114.000)
2
612.097.110
Plate, Outer Diaphragm Assy.
(Not Used with 286.114.000)
2
612.097.112
Plate, Outer Diaphragm Assy.
(Not Used with 286.114.000)
2
37
618.003.330
Plug, Pipe 1/4
2
38
618.003.330
Plug, Pipe 1/4 (Aluminum and Cast iron Units) 4
618.003.110
Plug, Pipe 1/4 (Stainless Units)
4
618.003.112
Plug, Pipe 1/4 (Hastalloy Units)
4
39
620.011.114
Plunger, Actuator
2
40
685.007.120
Rod, Diaphragm
1
41
720.004.360
Seal, U-Cup
2
42
722.010.110
Seat, Check Valve
2
722.010.110
“Seat, Check Valve - Suction Side
(PTFE and Santoprene Fitted Units)”
1
722.010.112
Seat, Check Valve
2
722.010.112
“Seat, Check Valve - Suction Side
(PTFE and Santoprene Fitted Units)”
1
722.031.110
“Seat, Check Valve - Discharge Side
(PTFE and Santoprene Fitted Units)”
1
722.031.112
“Seat, Check Valve - Discharge Side
(PTFE and Santoprene Fitted Units)”
1
43
807.017.330
Stud, Threaded (Side Port Units Only)
4
807.017.330
Stud, Threaded (Down Port Units Only)
8
44
900.005.330
Washer, Lock 3/8
6
45
900.006.330
Washer, Lock 7/16 (Side Ported Units)
20
900.006.330
Washer, Lock 7/16 (Down Ported Units)
24
46
905.001.330
Washer, Tapered
4
47
312.020.156
Elbow (Down Ported Units)
2
312.020.110
Elbow (Down Ported Units, SST & C.I.)
2
312.020.112
Elbow (Down Ported Units)
2
48
545.004.330
Nut, Hex 5/16-18 (Down Ported Units)
2
50
900.004.330
Washer, Lock 5/16 (Down Ported Units)
2
51
685.032.080
Rod, Connecting (Down Ported Units)
1
Item Part Number Description
Qty.
1
031.019.156
Assembly, Main Air Valve (Aluminum Center)
1
031.019.010
Assembly, Main Air Valve (Cast Iron Center)
1
2
050.005.360W
Ball, Check
4
050.005.363
Ball, Check
4
050.005.364
Ball, Check
4
050.005.365W
Ball, Check
4
050.005.354
Ball, Check
4
050.010.600
Ball, Check
4
3 070.006.170 Bearing
2
4
095.073.000
Assembly, Pilot Valve
1
5
114.002.156
Bracket, Intermediate
1
114.002.010
Bracket, Intermediate
1
6
115.046.080
Bracket, Leg (Side Ported Only)
2
115.057.080
Bracket, Leg (Down Ported Only)
2
7
132.002.360
Bumper, Diaphragm Rod
2
8
135.016.162
Bushing, Threaded
2
9
170.023.330
Capscrew, Hex Hd, 7/16-14 X 1.75
4
170.035.330
Capscrew, Hex Hd, 7/16-14 X 1.50
(Stainless Units Only)
4
10
170.024.330
Capscrew, Hex Hd, 7/16-14 X 1.00
4
11
170.035.330
Capscrew, Hex Hd, 7/16-14 X 1.50
4
12
170.040.330
Capscrew, Hex Hd, 3/8-16 X 5.50
6
13
170.045.330
Capscrew, Hex Hd, 5/16-18 X 1.25
4
14
170.058.330
Capscrew, Hex Hd, 7/16-14 X 1.25
4
15
170.060.330
Capscrew, Hex Hd, 7/16-14 X 2.00
12
16
196.193.156
Chamber, Outer (Includes Plug-Item #38)
2
196.193.010
Chamber, Outer (Includes Plug-Item #38)
2
196.193.110
Chamber, Outer (Includes Plug-Item #38)
2
196.193.112
Chamber, Outer (Includes Plug-Item #38)
2
17
196.194.156
Chamber, Inner (Includes Plug - Item #37)
2
196.194.010
Chamber, Inner (Includes Plug - Item #37)
2
18 286.005.360 Diaphragm
2
286.005.363 Diaphragm
2
286.005.364 Diaphragm
2
286.005.365 Diaphragm
2
286.005.354 Diaphragm
2
286.114.000 Diaphragm,
One-Piece Bonded PTFE Diaphragm
2
19
286.020.604
Diaphragm, Overlay
2
20
334.006.156
Flange, Discharge
1
334.006.010
Flange, Discharge
1
334.006.110
Flange, Discharge
1
334.006.112
Flange, Discharge
1
21
334.007.156
Flange, Suction
1
334.007.010
Flange, Suction
1
334.007.110
Flange, Suction
1
334.007.112
Flange, Suction
1
22
334.008.156
Flange, Threaded
2
334.008.010
Flange, Threaded
2
334.008.110
Flange, Threaded
2
334.008.112
Flange, Threaded
2
334.008.156E
Flange, Threaded (HDB40 Only) BSP Thread 2
334.008.010E
Flange, Threaded (HDB40 Only) BSP Thread 2
334.008.110E
Flange, Threaded (HDB40 Only) BSP Thread 2
334.008.112E
Flange, Threaded (HDB40 Only) BSP Thread 2
23
360.017.379
Gasket, Manifold / Seat
4
360.017.384
Gasket, Manifold / Seat
4
360.017.608
Gasket, Manifold / Seat
4
24
360.022.425
Gasket, Manifold (Side Ported Units)
2
360.022.425
Gasket, Manifold (Down Ported Units)
4
360.022.600
Gasket, Manifold (Side Ported Units)*
2
360.022.600
Gasket, Manifold (Down Ported Units)*
4
* PTFE and FKM Fitted Units Only
LEGEND:
= Items contained within Air End Kits
= Items contianed within Wet End Kits
Note: Kits contain components specific to the material codes.
MODEL SPECIFIC
3: EXP
VIEW
