Page 24

24
Cutterhead Parts List and Explosion Diagram
Index
No.
1
2
3
4
5
6
7
9
10
11
12
13
14
17
18
Description
Cutterhead
Knife
Knife Lock Bar
Bearing Housing
Bearing Housing
Cutterhead Pulley
Hex Screw/Cutterhead Locking
Key
Stud Bolt 10mm
Lock Washer 10mm
Screw/Cutterhead Set
Ball Bearing 62032
Ball Bearing 62022
Flat Washer 10mm
Hex Bolt M6x10
Q’ty
1
3
3
1
1
1
12
1
2
2
6
1
1
2
1
Part
No.
MB41010001
MB41010002
MB41010003
MB41010004
MB41010005
MB41010006
MB41010007
MB41010009
MB41010010
MB41010011
MB41010012
MB41010013
MB41010014
MB41010017
MB41010018
