RIKON Power Tools 70-300 - Manual (Page 25)

25
Parts List
Part No.
Spur Center
Set Screw M6x15
Face Plate
Spindle
Key 5x5x30
Ball Bearing 6207Z
Ball Bearing 6206Z
C-Ring C-62
C-Ring C-30
Index Pin
Headstock
Wire
Lever
Lever handle
Braking Resistor
Screw M5x12
Screw M5x12
Inverter
Bracket
Strain Relief
Power Cord
Set Screw M3x12
Strain Relief
Poly-V Belt HM180J
Set Screw M8x15
Spindle Pulley
Screw M5x12
Cover Plate
Hand Wheel
Knockout Rob
Motor
Set Screw M6x15
Key 5x5x45
Motor Pulley
70-300-B1
70-300-B2
70-300-B3
70-300-B4
70-300-B5
70-300-B6
70-300-B7
70-300-B8
70-300-B9
70-300-B10
70-300-B11
70-300-B12
70-300-B13
70-300-B14
70-300-B15
70-300-B16
70-300-B17
70-300-B18
70-300-B19
70-300-B20
70-300-B21
70-300-B22
70-300-B23
70-300-B24
70-300-B25
70-300-B26
70-300-B27
70-300-B28
70-300-B29
70-300-B30
70-300-B31
70-300-B32
70-300-B33
70-300-B34
Description Part No. Description
70-300-B35
70-300-B36
70-300-B37
70-300-B38
70-300-B39
70-300-B40
70-300-B41
70-300-B42
70-300-B43
70-300-B44
70-300-B45
70-300-B46
70-300-B47
70-300-B48
70-300-B49
70-300-B50
70-300-B51
70-300-B52
70-300-B53
70-300-B54
70-300-B55
70-300-B56
70-300-B57
70-300-B58
70-300-B59
70-300-B60
70-300-B61
70-300-B62
70-300-B63
70-300-B64
70-300-B65
70-300-B66
70-300-B67
70-300-B68
Set Screw M6x15
Hex Socket Cap Screw
Hex Socket Cap Screw
Washer 10
Motor Assembly Plate
Knob
Hex Nut M18
Clamp
Clamp Bolt
Bushing
C-Ring C-26
Index Bracket
Angular Setting Assembly
Spring
Spindle Lock Pin
Plate
Bracket
Hex Socket Cap Screw M5x15
Screw M5x12
Belt Door
Variable Speed Knob
Variable Speed Control
FWD/REV Switch-- HY60B
Push Button Switch-- HY57B
RPM Plate
Cover Plate
Digital Readout box
Hex Nut M4
Sensor
Digital Readout
Screw M5x12
Screw M3x70
Panel cover
C-Ring C-18
Headstock Assembly
