Parts List

Part No.

Stand Leg

Bed

Bushing

Tool Support Rod

C-Ring

C-Ring

Tool Rest Base

Tool Rest

Tool Support Handle

Lever

Center

Quill

Clamp Bolt

Bushing

Lead Screw

Lever

C-Ring C-18

Pin

Tail Stock Quill Handle

Tail Stock

Set Screw M6x12

Handwheel

Hex Head Bolt

Washer

Clamp

Nut M18

Nut M10

Adjustable Foot

70-300-A1

70-300-A2

70-300-A3

70-300-A4

70-300-A5

70-300-A6

70-300-A7

70-300-A8

70-300-A9

70-300-A10

70-300-A11

70-300-A12

70-300-A13

70-300-A14

70-300-A15

70-300-A16

70-300-A17

70-300-A18

70-300-A19

70-300-A20

70-300-A21

70-300-A22

70-300-A23

70-300-A24

70-300-A25

70-300-A26

70-300-A27

70-300-A28

Description

Stand and Bed Assembly
