7
Assembly
4. Position table support (33) in corresponding holes on side of base as shown in below
illustration.
5. Place washer (32) on knob (34) shaft and insert through slot into threaded holes in base.
6. Loosen the three hex. screws (31) and adjust table so that there is a maximum of 1.5mm
(1/16”) space between the sanding disc and the table. Tighten screws.
Index Pin
Table Support (33)
Base
Washer (32)
Knob (34)
Table Angle Scale
1/16 in. Max
between
Sanding surface and
Table Edge
Operation
The rocker ON/OFF power switch is located on the front of the sander, and incorporates a removable
safety switch.
1. Press the side marked ON to turn the sander on.
2. Press the side marked OFF to turn the sander off.
In situations where the sander may be left unattended, the operator has the option of removing the
center safety portion of the ON/OFF switch to render the sander inoperable. When the operator is
ready to use the machine again, the center safety portion of the switch may be reinstalled simply by
inserting it into the opening in the switch and pushing it in until it “seats”.
