Safety Warnings..................................................................................................................................2-3
Sander Safety Rules ..........................................................................................................................3
Specifications ........................................................................................................................................4
Unpacking ............................................................................................................................4
Assembly ...........................................................................................................................5
Mounting Sanding Disc and Guard.........................................................................................................5
Assembling the Work Support Fence..........................................................................................6
Table Support Assembly....................................................................................................................6
Mounting the Table Assembly..................................................................................................7
Operation ...........................................................................................................................................7
On/Off Switch ............................................................................................................................................8
Leveling the Table Assembly..........................................................................................................8
Installing the Sanding Belt ..........................................................................................................................9
Electrical Requirements.......................................................................................................................10
Wiring Diagram.................................................................................................................................11
Maintenance ...................................................................................................................................11-13
Timing Belt Replacement............................................................................................................................13
Trouble Shooting................................................................................................................................13
Parts List/Parts Explosion............................................................................................................................14-15
4
When unpacking, check to make sure the following parts are included. If any parts are missing
or broken, please call RIKON Power Tools at the number on the cover of this manual as soon as
possible.
Item # Description Qty
---- Sander Body 1
35 Table 1
7 6” Sandpaper Disc 1
33 Table Support 1
6 Guard, Disc 1
60 Work Support 1
---- Miter Gauge 1
---- Plastic bag contains 1
assembly hardware.
4”x36”
1930 SFPM
6”
3420 SFPM
9” x 6-1/4”
0-90 o
45 o
1/2 HP
4.3
110
37 lbs
Belt Size
Belt Speed
Disc Size
Disc Speed
Table Size
Belt Table Tilt
Disc Table Tilt
Motor
Amps
Volts
Net weight
Notes/Warranty .............................................................................................................................................15-16
Table of Contents
Specifications
Unpacking
