11
Disconnect machine from the power source.
WARNING!
1. Turn off and disconnect the power to the Drill
Press.
2. Open belt cover.
3. Release the locking knobs on the both sides
of drill press head. Release the tension on the
belt by swinging the tension lever from right to left
(Figure 15).
4. Choose the desired speed by referring to the
speed selection chart.
5. Place the belt on the pulleys in relation to the
speed chosen on the speed selection chart start-
ing with the motor pulley first. (Figure 16).
6. Swing back the tension lever until there is ap-
proximately 1/2” deflection in the belt.
7. Tighten the locking knob on the both sides of
drill press head.
8. Close the belt guard.
Changing spindle speeds
Figure 15
Figure 16
