Assembly
A
8
The 10-370 Bandsaw is supplied partly assembled.
Prior to use, the following items have to be assembled:
switch, working table, rip fence and hand-wheels.
To ensure sufficient upright stability and safety of this
bandsaw, you need to bolt the bandsaw to the floor with
M10 screws.(Fig 1) (not supplied).
Installing the Switch Box
Remove the two screws that were pre-installed on the
bandsaw column (A-Fig.2). These screws will be used
to mount the switch box to the column.
Loosen the four screws (A-Fig.3) on the front of the
switch box with a flat-head screw driver. Carefully
separate the control panel from the switch box.
Take extra care when handling the control panel as
wires are attached to the switch box. Do not allow the
control panel to be supported or hang by the wiring as
damage can occur to the electronics.
Figure 1
Figure 2
Figure 3
A
Caution!
Warning!
Mounting Holes
