Assembly Instructions
Shed House Style 8 x 8 x 8
V1.0
Do NOT Return Assembly To Dealer or Store. For All Questions or Shortages Please Call MDM Products Directly
Customer Service 800-447-7079 or 203-877-7070
Door Hold Ups
All MDM Products doors are manufactured with a pocket
on the bottom edge along the width axis. A ½” to 1”
plastic or metal tube can be inserted into the pocket and
trimmed to fit width. Weight will reduce door movement
in wind. Four(4) bungee straps are provided to retain
the door up. Roll the door from the bottom and secure
the door roll with a bungee through the upper door
grommet as shown.
Maintenance and Care
Annually or more often, the unit should be completely
inspected internally and externally to make certain the
unit remains properly installed and secured. Particular
attention should be paid to:
Hardware – check all carriage bolts and hardware
connectors to be certain they are in place and tightened.
Anchors – during normal weather trends, the unit will
strain against the anchors under windy conditions.
Anchor hardware connection to frame members should
be maintained tight and depth of anchors should be
checked to be certain they remain deeply and firmly set.
Snow Accumulation – all snow accumulation on the main
cover should be removed as soon as practical. The
days following the snowfall when the snow melts are
when most snow damage can occur. Unit is not
designed for any amount of accumulated snow or ice.
Tap the main cover from the inside with a broom end to
knock off any accumulated snow.
Main Cover Lacing – the poly rope that secures the main
cover to the bottom rail of the frame assembly should be
checked, and adjusted as needed. The tension on the
main cover should be uniform from end to end and side
to side. Rope ends must be tied off onto the frame
members at the ends on each side.
Turnbuckle Adjustment – during normal wind conditions
and load, the doors and main cover adjustment points at
the turnbuckle should be checked and tightened as
necessary. The turnbuckles should be neither
completely extended nor taken up, so that turnbuckle
should be tight when in the mid range of overall
adjustment. If necessary, readjust rope tie off on
turnbuckle as needed to tighten or loosen as needed.
Cleaning – cover and doors can be cleaned with a
mixture of light detergent and water. A soft bristle brush
with the mixture can be used to loosen any hard dirt,
mold, or buildup on the cover. After cleansing, the cover
should be rinsed thoroughly to avoid any chemical
reaction from residual detergent. Allowing dirt and
debris to sit on cover over an extended time will damage
cover irreparably.
Severe Weather – in preparation for inclement weather,
completely secure the doors on both ends of your MDM
Products shelter/garage. Allowing wind to enter either
end lifts the building and puts undue stress on the
anchoring system. This also shortens the life of the
doors, zippers, and main cover.
