VANTAGE® 300
1. Output rating in watts is equivalent to volt-amperes at unity power factor. Output voltage is within ± 10% at all loads up to rated capacity.
When welding, available auxiliary power will be reduced.
* Engine warranty may vary outside of the USA. (See Engine warranty for details).
** To Top of enclosure, add 7.88”(200.2mm) to top of exhaust pipe. Add 4.012”(101.9mm) to top of Lift Bail.
A-1 INSTALLATION A-1
TECHNICAL SPECIFICATIONS - VANTAGE® 300 (K2409-2)
INPUT - DIESEL ENGINE
RATED OUTPUT @ 104° F (40° C) - WELDER
HEIGHT WIDTH DEPTH WEIGHT
35.94** in. 25.30 in 60.00 in. 1035 lbs. (469kg.)
913 mm 643 mm 1524 mm
LUBRICATION EMISSIONS FUEL SYSTEM GOVERNOR
Full Pressure EPA Mechanical Fuel Pump, Auto air bleed Mechanical
with Full Flow Filter Tier 4 Interim Compliant system Electric shutoff solenoid Indirect fuel injector. Electronic
AIR CLEANER ENGINE IDLER MUFFLER ENGINE PROTECTION
Low noise Muffler: Shutdown on low oil
Single Element Automatic Idler Top outlet can be rotated. pressure & high engine
Made from long life, aluminized steel. coolant temperature
ENGINE WARRANTY: 2 year complete (parts and labor) 3rd. year major components (parts and labor)
Welding Process
DC Constant Current
DC Pipe Current
Touch-Start™TIG
DC Constant Voltage
Output Range
20 TO 400 AMPS
40 TO 300 AMPS
20 TO 250 AMPS
14 TO 32 VOLTS
Max. Weld OCV
@Rated Load RPM
60 Volts
Welding Output
Current/Voltage/Duty Cycle
300A / 32V / 100%
350A / 28V / 100%
300A / 32V / 100%
250A / 30V / 100%
300A / 32V / 100%
350A / 28V / 100%
Auxiliary Power 1
11,500 Watts Peak, / 10,000 Watts Continuous, 60 Hz 120/240 Volts Single Phase
12,500 Watts Peak, /11,000 Watts Continuous, 60 Hz, 240 Volts 3-Phase
PHYSICAL DIMENSIONS
ENGINE
RATED OUTPUT @ 104° F (40° C) . - GENERATOR
Make/Model
K2409-2
Kubota*
V1505
Description
4 Cylinder
naturally
aspirated
Water Cooled
Diesel Engine
Horsepower
@ 1800 RPM
22 HP
Operating
Speed (RPM)
High
1890 RPM
Full Load
1800 RPM
Low Idle
1350 RPM
Displacement cu. in. (ltrs.)
Bore x Stroke inch (mm)
91.41(1.5)
3.07 x 3.09 (78 x 78)
Starting
Systems
12VDC Battery
and starter
(Group 34;
Battery 535 cold
crank amps)
Battery Charger
Capacities
Fuel: 15gal.(57L)
Oil: 6.4qts.(6.0L)
Radiator
Coolant:
7.2qts.(6.8L)
