Installation – Lincoln Electric IM951 VANTAGE 300 User Manual
Page 10
A-2
INSTALLATION
VANTAGE® 300
A-2
RECEPTACLES AUXILIARY POWER CIRCUIT BREAKER OTHER CIRCUIT BREAKERS
(2) 120VAC GFCI Duplex (5-20R) Two 20AMP for Two Duplex Receptacle 10AMP for Engine Battery
(1) 120/240VAC Dual Voltage (1) 50Amp for Dual Voltage and 3-Phase (3-pole) Charging Circuit
Full KVA (14-50R)
10AMP for 42V Wire Feeder Power
(1) 240VAC 3-Phase (15-50R)
MACHINE SPECIFICATIONS
