C-2 ACCESSORIES C-2
READI-REEL ADAPTERS:
K363P - Adapts Lincoln Readi-Reel coils of electrode 30 lb
(14 kg) and 22 lb (10 kg) to a 2
” (51mm) spindle. Durable
molded plastic one piece construction. Designed for easy
loading; adapter remains on spindle for quick changeover.
(used with K162H)
K438 - Adapts Lincoln Readi-Reel coils of electrode 50-60 lb
(22.7-27.2 kg) to a 2
” (51mm) spindle. (used with K162H) .
GUN AND CABLE ASSEMBLIES:
The following Lincoln gun and cable assemblies are com-
patible with both the Synergic 7F and Synergic 7FH Wire
Feed units:
K126 - Innershield ® gun and cable assemblies are rated at
350 amps, 60% duty cycle. Maximum wire size for Synergic
7F models is 5/64
” (2.0 mm). Not recommended for
Synergic 7FH models. (Consult sales specifications for
appropriate models).
K115 - Innershield gun and cable assemblies are rated at
450 amps, 60% duty cycle. Maximum wire size for Synergic
7F models is 5/64
” (2.0 mm). Not recommended for
Synergic 7FH models. (Consult sales specifications for
appropriate models).
K470 - Magnum 300 GMAW gun and cable assemblies are
rated for 300 amps, 60% duty cycle. (Consult sales specifi-
cations for appropriate models).
K471 - Magnum 400 GMAW gun and cable assemblies are
rated for 400 amps, 60% duty cycle. (Consult sales specifi-
cations for appropriate models).
K497 - Magnum 200 GMAW gun and cable assemblies are
rated 200 amps, 60% duty cycle. (Consult sales specifica-
tions for appropriate models).
K541 - Magnum 400 Short Neck GMAW gun and cable
assemblies are rated 400 amps, 60% duty cycle. (Consult
sales specifications for appropriate models).
K598 - Magnum 550 GMAW gun and cable assemblies are
rated 550 amps, 60% duty cycle. (Consult sales specifica-
tions for appropriate models).
K206* - Innershield Linconditioner gun and cable assem-
blies are rated 350 amps, 60% duty cycle. Maximum size for
Synergic 7F Wire Feed unit is 5/64
” (2.0 mm). Not recom-
mended for Synergic 7FH Wire Feed unit. (Consult sales
specifications for appropriate models).
K289* - Innershield Linconditioner gun and cable assem-
blies are rated 500 amps, 60% duty cycle. Maximum size for
Synergic 7F Wire Feed unit is 5/64
” (2.0 mm). Not recom-
mended for Synergic 7FH Wire Feed unit. (Consult sales
specifications for appropriate models).
K309* - Innershield Linconditioner gun and cable assem-
blies are rated 250 amps, 60% duty cycle. Maximum size for
Synergic 7F Wire Feed unit is 5/64
” (2.0 mm). Not recom-
mended for Synergic 7FH Wire Feed unit. (Consult sales
specifications for appropriate models).
The following Lincoln gun and cable assemblies are
equipped with a Fast-Mate
™ connector. They can be
used with Synergic 7F Wire Feed unit by installing a
K489-2 Fast-Mate adapter kit.
K684 - Magnum “ Super Cool ” FM water cooled
GMAW gun and cable assemblies are rated 450
amps, 100% duty cycle (CO
2
). (Consult sales specifi-
cations for appropriate models).
K498 - Magnum 200 FM GMAW gun and cable
assemblies are rated for 200 amps, 60% duty cycle.
(Consult sales specifications for appropriate models).
K534 - Magnum 250L FM GMAW gun and cable
assemblies are rated for 250 amps, 30% duty cycle.
(Consult sales specifications for appropriate models).
K478 - Magnum 300 FM GMAW gun and cable
assemblies are rated for 300 amps, 60% duty cycle.
(Consult sales specifications for appropriate models).
K479 - Magnum 400 FM GMAW gun and cable
assemblies are rated for 400 amps, 60% duty cycle.
(Consult sales specifications for appropriate models).
K556 * - GMAW process Magnum 400XA X-TRAC-
TOR gun and cable assemblies are rated at 400
amps, 60% duty cycle. (Consult sales specifications
for appropriate models).
K566 * - GMAW process Magnum 250XA X-TRAC-
TOR gun and cable assemblies are rated 250 amps,
60% duty cycle. (Consult sales specifications for
appropriate models).
* K179 type vacuum unit not recommended for use with
Synergic 7F.
