– 11 –
MISCELLANEOUS OPTIONS:
K682 Water Connection Kit - Includes water cooled gun
tube fittings and self-sealing outlet and inlet quick-
connectors for mounting onto the Synergic 7F Wire Drive
mounting bracket.
K659-1 - (Gas Guard Regulator) Adjustable flow regulator
with removable adjustor key for CO
2
and Argon blend gases.
Mounts onto Wire Drive gas inlet, and reduces gas waste
and arc start “blow” by reducing surge caused by excess
pressure in supply hose.
K683-1 - (Dual Procedure Switch) Kit includes gun switch
and mountings for Lincoln Innershield and Magnum guns
with 15 ft (4.6 m) control cable and 3-pin plug.
K541 - Magnum 400 Short Neck GMAW gun and cable
assemblies are rated 400 amps, 60% duty cycle. (Consult
sales specifications for appropriate models).
K598 - Magnum 550 GMAW gun and cable assemblies are
rated 550 amps, 60% duty cycle. (Consult sales
specifications for appropriate models).
K206* - Innershield Linconditioner gun and cable
assemblies are rated 350 amps, 60% duty cycle. Maximum
size for Synergic 7F Wire Feed unit is 5/64” (2.0 mm). Not
recommended for Synergic 7FH Wire Feed unit. (Consult
sales specifications for appropriate models).
K289* - Innershield Linconditioner gun and cable
assemblies are rated 500 amps, 60% duty cycle. Maximum
size for Synergic 7F Wire Feed unit is 5/64” (2.0 mm). Not
recommended for Synergic 7FH Wire Feed unit. (Consult
sales specifications for appropriate models).
K309* - Innershield Linconditioner gun and cable
assemblies are rated 250 amps, 60% duty cycle. Maximum
size for Synergic 7F Wire Feed unit is 5/64” (2.0 mm). Not
recommended for Synergic 7FH Wire Feed unit. (Consult
sales specifications for appropriate models).
The following Lincoln gun and cable assemblies are
equipped with a Fast-Mate™ connector. They can be
used with Synergic 7F Wire Feed unit by installing a
K489-2 Fast-Mate adapter kit.
K684 - Magnum “Super Cool” FM water cooled
GMAW gun and cable assemblies are rated 450
amps, 100% duty cycle (CO
2
). (Consult sales
specifications for appropriate models).
K498 - Magnum 200 FM GMAW gun and cable
assemblies are rated for 200 amps, 60% duty cycle.
(Consult sales specifications for appropriate models).
K534 - Magnum 250L FM GMAW gun and cable
assemblies are rated for 250 amps, 30% duty cycle.
(Consult sales specifications for appropriate models).
K478 - Magnum 300 FM GMAW gun and cable
assemblies are rated for 300 amps, 60% duty cycle.
(Consult sales specifications for appropriate models).
K479 - Magnum 400 FM GMAW gun and cable
assemblies are rated for 400 amps, 60% duty cycle.
(Consult sales specifications for appropriate models).
K556 * - GMAW process Magnum 400XA X-
TRACTOR gun and cable assemblies are rated at 400
amps, 60% duty cycle. (Consult sales specifications
for appropriate models).
K566 * - GMAW process Magnum 250XA X-
TRACTOR gun and cable assemblies are rated 250
amps, 60% duty cycle. (Consult sales specifications
for appropriate models).
* K179 type vacuum unit not recommended for use with
Synergic 7F.
