A-1
A-1 INSTALLATION
SP-175 PLUS
TECHNICAL SPECIFICATIONS – SP-175 Plus
Fuse or
Output Mode Input Voltage Breaker Size Input Amps Power Cord
RATED 230V/60Hz 40 Super Lag 21/23 50 Amp, 250V,
208V/60Hz Three-Prong Plug
(NEMA Type 6-50P)
INPUT – SINGLE PHASE ONLY
RATED OUTPUT
OUTPUT
RECOMMENDED INPUT CABLE AND FUSE SIZES
Height Width Depth Weight
12.0 in 9.75 in 16.5 in 60 Ibs
305 mm 248 mm 419 mm 27.3 kg
PHYSICAL DIMENSIONS
Standard Voltage/Frequency Input Current
230V/60Hz 21 Amps @ Rated Output
208V/60Hz 23 Amps @ Rated Output
Duty Cycle Current Voltage
30% Duty Cycle @ 230V/60Hz 130 Amps 20 V
25% Duty Cycle @ 208V/60Hz 130 Amps 20 V
Welding Current Range Maximum Open Circuit Voltage Wire Speed Range
Rated DC Output: 30 – 175 amps 33 50-400IPM (1.3-10.2m/min)
