DX450 (RED-D-ARC)
A-1 INSTALLATION A-1
1. Output rating in watts is equivalent to volt-amperes at unity power factor. Output voltage is within ± 10% at all loads up to
rated capacity. When welding, available auxiliary power will be reduced.
* To Top of enclosure, add 10.68”(271.3mm) to top of exhaust pipe. Add 6.67”(169.4mm) to top of Lift Bail.
2. Reduced to less than 32V in the CC-stick Mode when VRD (VOLTAGE REDUCTION DEVICE) is on.
TECHNICAL SPECIFICATIONS - DX450 (K2712-1, K3211-1)
Make/Model Description Speed (RPM) Displacement Starting Capacities
cu. in. (ltrs.) System
4 cylinder 148.5(2.4) 12VDC Battery & Fuel: 20 gal.
35.4 HP High Idle 1880 starter (75 L)
KUBOTA 1800 RPM Bore x Stroke inch (mm) (Group 34; 650 Oil: 10Qts. (9.5L)
2403-M Full Load 1800 3.43” X 4.03” cold crank amps)
(87.1 x 102.4mm) 40 Amp Radiator Coolant:
Low Idle 1400 Alternator 8.0 Qts. (7.6L)
INPUT - DIESEL ENGINE
RATED OUTPUT @ 104° F (40° C) - WELDER
LUBRICATION EMISSIONS FUEL SYSTEM GOVERNOR
Full Pressure EPA Tier 4 Interim Mechanical Fuel Pump, Auto air bleed Electronic
with Full Flow Filter Compliant system, Electric shutoff solenoid, Indirect fuel injector.
AIR CLEANER ENGINE IDLER MUFFLER ENGINE PROTECTION
Low noise Muffler: Shutdown on low oil
Single Element Automatic Idler Top outlet can be rotated. pressure & high engine
Made from long life, aluminized steel. coolant temperature
Welding Process
DC Constant Current
DC Pipe Current
Touch-Start™TIG
DC Constant Voltage
Arc Gouging
Output Range
30 TO 500 AMPS
40 TO 300 AMPS
20 TO 250 AMPS
14 TO 36 VOLTS
90 TO 450 AMPS
Max. Weld OCV
@Rated Load RPM
60 Volts
2
Welding Output
Current/Voltage/Duty Cycle
400A / 36V / 100%
450A / 32V / 100%
300A / 32V / 100%
250A / 30V / 100%
400A / 36V / 100%
450A / 32V / 100%
400A / 36V / 100%
Auxiliary Power 1
12,000 Watts Peak, / 11,000 Watts Continuous, 60 Hz 120/240 Volts Single Phase
19,000 Watts Peak, / 17,000 Watts Continuous, 60 Hz, 240 Volts 3-Phase
ENGINE
RECEPTACLES AUXILIARY POWER CIRCUIT BREAKER OTHER CIRCUIT BREAKERS
(2)120VAC Duplex (5-20R)GFCI Protected Two 20AMP for Two Duplex Receptacle 10AMP for Battery Charging Circuit
(1) 120/240VAC Dual Voltage (1) 50AMP for Dual Voltage and for 10AMP for 42V Wire Feeder Power
Full KVA (NEMA SSR-50R) 3-Phase (3-pole)
(1) 240VAC 3-Phase (15-50R)
MACHINE SPECIFICATIONS
RATED OUTPUT @ 104° F (40° C) . - GENERATOR
HEIGHT WIDTH DEPTH WEIGHT
35.94* in. 25.30 in 60.00 in.
913 mm 643 mm 1524 mm
PHYSICAL DIMENSIONS
1245lbs. (565kg.)
LIFT BAIL WEIGHT RATING 2000 LBS. (907KG.) MAXIMUM
