Carbon Diameter Current Range (DC, electrode
positive)
1/8"(3.2mm) 60-90 Amps
5/32"(4.0mm) 90-150 Amps
3/16"9(4.8mm) 200-250 Amps
1/4"(6.4mm) 300-400 Amps
5/16"(8.0mm) 400-Max.Amps
AUXILIARY POWER:
Start the engine and set the IDLER control switch to
the desired operating mode. Full power is available
regardless of the welding control settings providing no
welding current is being drawn.
Simultaneous Welding and Auxiliary Power Loads
The auxiliary power ratings are with no welding load.
Simultaneous welding and power loads are specified
in Table B.5.
DX450 Extension Cord Length Recommendations
(Use the shortest length extension cord possible sized per the following table.)
Current
(Amps)
15
20
15
20
44
Voltage
Volts
120
120
240
240
240
Load
(Watts)
1800
2400
3600
4800
9500 30
60
(9)
(18)
40
30
75
60 (12)
(9)
(23)
(18)
75
50
150
100
50
(23)
(15)
(46)
(30)
(15) 125
88
225
175
90
(38)
(27)
(69)
(53)
(27) 175
138
350
275
150 (53)
(42)
(107)
(84)
(46)
300
225
600
450
225 (91)
(69)
(183)
(137)
(69)
Maximum Allowable Cord Length in ft. (m) for Conductor Size
Conductor size is based on maximum 2.0% voltage drop.
14 AWG 12 AWG 10 AWG 8 AWG 6 AWG 4 AWG
B-7 OPERATION B-7
DX450 (RED-D-ARC)
This will keep the "Solid State" contactor open and provide a
"cold" electrode until the Amptrol or Arc Start Switch is pressed.
When using the TIG Module, the OUTPUT CONTROL on the
DX450 is used to set the maximum range of the CURRENT
CONTROL on the TIG Module or an Amptrol if connected to the
TIG Module.
NOTE: The TIG process is to receive a low voltage welding
process. There is no difference in operation with the
VRD “On” or “Off” for this mode. For indicator light oper-
ation, see table B.1.
WIRE WELDING-CV
Connect a wire feeder to the DX450 according to the instruc-
tions in INSTALLATION INSTRUCTIONS Section.
The DX450 in the CV-WIRE mode, permits it to be used with a
broad range of flux cored wire (Innershield and Outershield)
electrodes and solid wires for MIG welding (gas metal arc weld-
ing). Welding can be finely tuned using the ARC CONTROL.
Turning the ARC CONTROL clockwise from –10 (soft) to +10
(crisp) changes the arc from soft and washed-in to crisp and
narrow. It acts as an inductance/pinch control. The proper set-
ting depends on the procedure and operator preference. Start
with the dial set at 0.
NOTE: In the CV-Mode with VRD “On”, the OCV(Open Circuit
Voltage) is not reduced. For indicator light operation,
see table B.1.
ARC GOUGING
The DX450 can be used for arc gouging. For optimal
performance, set the MODE switch to ARC GOUGING.
TABLE B.6
Set the OUTPUT CONTROL knob to adjust output
current to the desired level for the gouging electrode
being used according to the ratings in the following
Table B.4.
TABLE B.4
The ARC CONTROL is not active in the ARC GOUG-
ING Mode. The ARC CONTROL is automatically set
to maximum when the ARC GOUGING mode is
selected which provides the best ARC GOUGING per-
formance.
NOTE: With the VRD switch in the “ON” position there
is no output in the Arc Gouging Mode. For indicator
light operation, see table B.1.
TABLE B.5 DX450 SIMULTANEOUS WELDING AND POWER LOADS
WELD
AMPS
0
100
200
300
400
500
1 PHASE
WATTS AMPS
11,000 46
11,100 46
8,000 33
4,700 20
1,700 7
0 0
3 PHASE
WATTS AMPS
17,000 41
15,400 37
13,000 31
9,400 23
3,400 8
0 0
BOTH 1 AND 3 PHASE
WATTS AMPS
11,000 -
11,000 -
8,000 -
4,700 -
1,700 -
0 0
PLUS OR OR
