Page 8
A-1
INSTALLATION
RED-D-ARC E300
A-1
TECHNICAL SPECIFICATIONS - RED-D-ARC E300 (TYPE K1688-1)
RATED OUTPUT - WELDER
RATED INPUT - WELDER
HEIGHT WIDTH
DEPTH
WEIGHT
27.00 in.*
9.00 in.
21.50 in.
350 lbs. (159 kg )
686 mm*
483 mm
546 mm
(159 kg)
OUTPUT
Current Range
Volts at Rated Amps
Duty Cycle
Max. OCV
DC 250 Amps
40-250 amps
30 volts
30%
70 volts
Auxiliary Power
15 Amps @ 115VAC
100 % Duty Cycle
PHYSICAL DIMENSIONS
AC Input Frequency
60 Hz
Input Power Standard Voltages
230/460/575
Rated Input Current (230V 60Hz)
86 amps
Idle Input Current (230V)
6.2 amps
Power Factor (200 Amp Load) 69.0
*
(Lift Hook, add 3.12 in.- 80 mm)
