POWERBrazer
B-1 B-1
FUMES AND GASES can be
dangerous.
• Keep your head out of fumes.
• Use ventilation or exhaust to
remove fumes from breathing
zone.
BRAZING MATERIALS MAY CONTAIN CADMIUM. FUMES
ARE POISONOUS AN CAN KILL.
• Do not breathe fumes. Even brief exposure to high concen-
trations should be avoided.
• Use enough ventilation, exhuast at the arc, or both, to keep
fumes and gases from your breathing zone and general
area. If this cannot be done, use air supplied respirators.
----------------------------------------------------------------------------------------
• Do not wear gloves when threading or
changing wire spool.
• Keep hands, hair, clothing and tool away
from rotating equipment.
----------------------------------------------------------------------------------------
FLAME and BRAZING SPARKS
can cause fire or explosion.
• Keep flammable material
away.
------------------------------------------------------------------------------
OPERATION
WARNING
GENERAL DESCRIPTION
The POWERBrazer is a specially engineered wire
feeder for brazing materials. As part of a patent
pending process, the POWERBrazer brings
productivity and efficiency gains to brazing
customers. A simple press of a button on the gun
feeds brazing wire at a controlled speed.
The heart of the POWERBrazer is the 2 roll
MAXTRAC™ drive. The patented features on the
wire drive offer tool-less changing of the drive rolls
and wire guides for quick spool changes. A
tachometer controlled motor powers the patent
pending drive rolls for smooth, steady feeding
without slippage.
With only one printed circuit board, the
POWERBrazer is designed to be simple, reliable
and easy to service.
RECOMMENDED PROCESSES
AND EQUIPMENT
K1500-1 Gun Bushing Installed
RECOMMENDED PROCESSES
• Semi-Automatic Brazing
PROCESS LIMITATIONS
• The POWERBrazer is intended for brazing only.
It cannot be used for arc welding.
EQUIPMENT LIMITATIONS
• The maximum spool size is 45lbs.(20.4Kg.),
12”(305mm) diameter.
• Maximum gun length is 15 ft.(4.6m).
SAFETY PRECAUTIONS
READ AND UNDERSTAND ENTIRE SECTION
BEFORE OPERATING MACHINE
USER SERVICEABILITY
The serviceability of a product or structure utilizing the
POWERBrazer is and must be the sole responsibility
of the builder/user. Many variables beyond the control
of the Harris Products Group affect the results
obtained in using the POWERBrazer. These variables
include, but are not limited to, brazing procedure,
plate chemistry and temperature, joint design, fabrica-
tion methods and service requirements. The available
range of the POWERBrazer may not be suitable for all
applications, and the builder/user is and must be sole-
ly responsible for welding settings.
