A-2 GENERAL DESCRIPTION
MAGNUM® 250 NR
A-2
Description
Gun Contact Tips
Product Cable Wire Size Heavy Gas less Nozzle Cable Gun Tube
Number Length (m) in. (mm) Duty Diffuser Insulator Liner 60°
K1614-2 15 ft. .035 (0.9) S19392-1 S24109-1 T12313 M16087-1 S24112-1
(4.5) .045 (1.2) -2
K1614-3 15 ft. .052 (1.3) S19392-3 S24109-2 T12313 M18997-1 S24112-1
(4.5) 1/16 (1.6) -4
.068 (1.7) -8
MAGNUM® 250 NR (250 ampers) AT 60% DUTY CYCLE
