PARTS
MAGNUM® 250 NR
CHART B
Contact Tips/ Part Number English Metric
Gas Less Diffuser (Industry Ref.) Wire Size Wire Size
Standard Duty S19391-1 (14-35) .035” 0.9 mm
-8 (14-40) .040” 1.0 mm
-2 (14-45) .045” 1.2 mm
-3 (14-52) .052” 1.3 mm
-4 (14-116) 1/16” 1.6 mm
Heavy Duty S19392-1 (14H-35) .035” 0.9 mm
-6 (14H-40) .040” 1.0 mm
-2 (14H-45) .045” 1.2 mm
-3 (14H-52) .052” 1.3 mm
-4 (14H-116) 1/16” 1.6 mm
-8 (14AH-116) .068” * 1.7 mm*
Tapered S19393-1 (14T-35) .035” 0.9 mm
-7 (14T-40) .040” 1.0 mm
-2 (14T-45) .045” 1.2 mm
-3 (14T-52) .052” 1.3 mm
-4 (14T-116) 1/16” 1.6 mm
Gas less Diffuser S24109-1 .035-.045” 0.9-1.2 mm
S24109-2 .052-.068” 1.3-1.7 mm
Nozzle Insulator T12313
CHART C
Part Number English Metric
Cable Liner (Industry Ref.) Wire Size Wire Size
For 15 ft (4.5 m) M16087-5 (42-3035-15) .030 - .035” 0.8-0.9 mm
and less M16087-1 (42-4045-15) .035 - .045” 0.9-1.2 mm
Trim to Fit M18997-1 .052 - .068” 1.3-1.7 mm
CHART A
Connector Kits (1)
Trigger Gas Tube
Product Feeder Power Lead and Connector
Number Type Connector Connector Fitting Tools
K466-1 Lincoln (2) ✔ ✔ ✔ ✔
K466-2 Tweco ✔ — — ✔
Adapted &
Lincoln -10 Series
K466-3 Miller ✔ ✔ — ✔
K466-4 Hobart 27 ✔ ✔ ✔ ✔
K466-5 L-Tec ✔ ✔ — ✔
Adapted
K466-6 Wirematic ✔ ✔ — ✔
K466-7 Hobart ✔ ✔ — ✔
Seires 2000
K466-8 Lincoln (3) ✔ ✔ ✔ ✔
K466-9 SP100T and ✔ ✔ — ✔
Related Units
(1) See Magnum 250 NR Parts Manual for part numbers.
(2) Except LN8 or LN9 using 1/16 and larger electrodes.
(3) LN8 or LN9 using 1/16 and larger electrodes.
(*) Tip stencilled 1/16A
