C-1 ACCESSORIES
LN™-23P
C-1
OPTIONAL EQUIPMENT
GUN AND CABLE ASSEMBLIES
K-350 ADAPTER KIT
Required when using the LN™-23P on any constant
voltage power source. Either one or two LN™-23P’s
can be connected to the Adapter. If two LN™-23P’s
are connected, they can be set for different proce-
dures. The Adapter circuit is interlocked so only one
LN™-23P can be used at a time.
Note: A K350 Adapter Kit is not applicable when
connecting a LN™-23P (Code 10892, 10917, 10918)
to a V350-Pipe.
K-276 ENCLOSED WIRE REEL SUPPORT
Bolts to the LN™-23P frame for feeding wire from
standard 50 lb. Innershield coils. Includes enclosure
and door to keep the dirt out; also includes wire reel
brake assembly.
Type K-355-10* K-345-10* K-264-8 K-361-10 K-406*
Length: 10 feet 10 feet 8 feet 10 feet Linconditioner Gun 10 ft.
(15 ft. Exhaust Hose)
Rated Welding
Current:
250 Amps 350 Amps 250 Amps 350 Amps 350 Amps
Duty Cycle 60% 60% 60% 60% 60%
Electrode Sizes .068, .072, 5/64 .068, .072, 5/64 068, .072, 5/64 068, .072, 5/64 068, .072, 5/64
Reduced Speed
Switch
stod. stod. None None stod.
Sizes 5/64 5/64 5/64 5/64 5/64
Nozzle Angle 90E 90E 62E 62E 68E
Weight 7.0 lbs. 89.3 lbs. 5.2 lbs. 7.5 lbs. 16.0 lbs.
* Recommended for pipe welding applications.
All guns include one each .068/.072 tip, 5/64 tip, and a thread protector**. The K-264-8 also includes an insulated guide for
3/4" to 1-1/2" strikeout. The K-361-10 also includes an insulated guide for 2" strikeout.** The K-406 includes an insulated
guide for 2" to 1" strikeout, but no thread protector.
