A-1 INSTALLATION
LF-72
A-1
TECHNICAL SPECIFICATIONS: LF-72 Wire Feeder
SPEC.# TYPE WIRE FEED SPEED RANGE
∅ Dimensions do not include wire reel.
Wire Size
LF-72 Speed Solid Cored
K2327-1
K2327-4
K2327-2 Bench Model
50-800 IPM .023 - 1/16 in. .035 - 5/64 in
K2327-5 Standard Duty (1.27-20.3 m/m) (0.6 - 1.6 mm) (0.9 - 2.0 mm)
K2327-3
K2327-6 Bench Model
K2327-7 Heavy Duty
CONTROL BOX, WIRE DRIVE AND COMPLETE UNITS
SPEC.# TYPE INPUT POWER PHYSICAL SIZE• TEMPERATURE RATING
Input Voltage Dimensions
and Current Height Width Depth Weight Operating Storage
43 Lbs
K2327-1 LF-72 11.1“ 10.2“ 12.9“ (19.7 Kg.)
( 282 mm) (259 mm) (328 mm)
K2327-4 Base Model 26.5 Lbs
(12.0 Kg)
Dimensions ∅
Height Width Depth Weight
LF-72
K2327-2 24-42VAC 12.6“ 10.9“ 22.5“ 52.5 Lbs 14°F to 104°F -40°F to 185°F
K2327-5 Bench 9 AMPS ( 320 mm) (277 mm) (572 mm) (23.8 Kg.) (-10°C to 40°C) (-40°C to 85°C)
Standard
Duty
Dimensions ∅
Height Width Depth Weight
K2327-3 LF-72
K2327-6 15.3“ 13.0“ 27.7“ 67.5 Lbs
K2327-7 Bench ( 389 mm) (330 mm) (704 mm) (30.6 Kg.)
Heavy
Duty
WELDING CAPACITY RATING
Amp Rating Duty Cycle
500 A 60%
Base Model
