3.0 Presentation

3.2 600VA UPS—220/230/240 Vac version

Rear view

IEC 320

output couplers

Compute

Interface port

See Sec. 6.4

IEC 320 inlet

Circuit breaker

Front view

Display

features

see Section 5.1

Test

button

see Sec. 5.1.8

Alarm disable

button

See Sec. 5.1.9

Power on

button

see Sec. 5.1.6

Power standby

button

see Sec. 5.1.7

UPS Enable switch

see Sec. 4.3

Option switches

see Sec. 5.5
