Troubleshooting, Caution – Lincoln Electric IM602 IDEALARC DC-655 User Manual
Page 32
E-6
TROUBLESHOOTING
E-6
DC-655
Observe all Safety Guidelines detailed throughout this manual
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
Local Lincoln Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
CAUTION
PROBLEMS
PROBLEMS
(SYMPTOMS)
POSSIBLE
CAUSE
RECOMMENDED
COURSE OF ACTION
Poor arc characteristics.
115VAC receptacle not working.
1. The negative welding cable may
be connected to the wrong induc-
tance tap.
2. Make sure the mode switch is in
the proper position for the
process.
3. The control board may be faulty.
See PC board LED information.
1. Check the 115VAC circuit break-
er. Reset if necessary. Make
sure the load on the receptacle
does not exceed the rating of the
115VAC breaker. See wiring dia-
gram.
Contact your Local Lincoln Authorized
Field Service Facility for technical
troubleshooting assistance.
