GX 300
1. Output rating in watts is equivalent to volt-amperes at unity power factor. Output voltage is within ± 10% at all loads up to
rated capacity. When welding, available auxiliary power will be reduced.
** 36.24(920.5mm) to top of exhaust.
A-1 INSTALLATION A-1
TECHNICAL SPECIFICATIONS - GX300 (K2284-1)
Make/Model Description Speed (RPM) Displacement Starting Capacities
cu. in. (cu. cm.) System
2 cylinder High Idle 3700 41(674) 12VDC Battery & Fuel: 12 gal.
Kohler CH22 Starter 45.4 L
22 HP @ Bore x Stroke inch (mm) (Group 58; 435 Oil: 2.0 Qts
3600 RPM Full Load 3500 cold crank amps) 1.9 L
3.03 x 2.85 (77 x 72) Battery Charger
INPUT - GASOLINE ENGINE
RATED OUTPUT @ 104° F (40° C) - WELDER
HEIGHT WIDTH DEPTH WEIGHT
29.9** in. 21.1 in 42.1 in.
759.0 mm 536.0 mm 1069.0 mm
LUBRICATION VALVE LIFTERS FUEL SYSTEM GOVERNOR
Full Pressure Hydraulic Mechanical Fuel Pump Mechanical Governor
with Full Flow Filter 5% Regulation
AIR CLEANER ENGINE IDLER MUFFLER ENGINE PROTECTION
Low noise Muffler: Top outlet Shutdown on low oil
Dual Element Automatic Idler can be rotated. Made from pressure.
long life, aluminized steel.
ENGINE WARRANTY: 2 year unlimited hours (See Kohler engine manufacturer warranty for details.)
Welding Output Volts at Rated Amps Duty Cycle Max. OCV @ 3700 RPM
CC STICK DC Output 29 Volts @ 305 Amps 100%
CC STICK Output Range 20 to 305 Amps -------
PIPE DC Output 29 Volts @ 300 Amps 100%
PIPE Output Range 40 to 300 Amps ------- 80 Volts
TIG Output Range 20 to 250 Amps -------
CV WIRE DC Output 29 Volts @ 300 Amps 100%
CV WIRE Output Range 14 to 29 volts -------
Auxiliary Power 1
10,000 Watts Peak, 9500 Watts Continuous, 60 Hz
120/240 Volts
PHYSICAL DIMENSIONS
ENGINE COMPONENTS
RATED OUTPUT @ 104° F (40° C) . - GENERATOR
510 lbs. (231kg.)
