KP1682 CLUTCHED ALUMINUM DRIVE ROLL KITS
KIT SIZES & CONTENTS
The table and figures below list and illustrates the various K1682 series clutched aluminum drive roll kits for the
various wire sizes. Included with each KP1682 series kit are the components needed for 2-roll and 4-roll feeders.
Each kit includes the following items:
Drive Roll Kit KP1682-035A KP1682-1.0A KP1682-3/64A KP1682-1/16A
Metric Wire Size 0.9 mm 1.0 mm 1.2 mm 1.6 mm
English Wire Size .035 in .040 in 3/64 in (.047) 1/16 in (.063)
Included Items
1
Clutch Bolt S24474 S24474 S24474 S24474
2 Spring T11862-59 T11862-59 T11862-59 T11862-59
3 Clutch Pad (Qty. 2) S24475 S24475 S24475 S24475
4 Drive Roll S24480-035A S24480-1.0A S24480-3/64A S24480-1/16A
5 Outgoing Guide Tube S24479-035A S24479-3/64A S24479-3/64A S24479-1/16A
The following items are to be used for 2-roll operation only:
6 Incoming Guide Tube S21273-3/64 S21273-3/64 S21273-3/64 S21273-1/16
7 Idle Roll Arm Assembly S16666-035A S16666-1.0A S16666-3/64A S16666-1/16A
8 Quick Release Arm M19287 M19287 M19287 M19287
9 Latch S24299 S24299 S24299 S24299
10 Torsion Spring S24300 S24300 S24300 S24300
11 Speed Clip T10982-7 T10982-7 T10982-7 T10982-7
The following items are to be used for 4-roll operation only:
12 Incoming Guide Tube S21273-3/64F S21273-3/64F S21273-3/64F S21273-1/16F
13 Idle Roll and Shaft Assembly S24472-035A S24472-1.0A S24472-3/64A S24472-1/16A
14 Middle Guide Tube M17509-3/64 M17509-3/64 M17509-3/64 M17509-1/16
