V350-PIPE
A-1 INSTALLATION A-1
TECHNICAL SPECIFICATIONS - INVERTEC V350-PIPE
INPUT AC VOLTAGE & DC OUTPUT
Product Ordering Input AC Rated DC Output Output Open
Name Information Voltage Amps/Volts/Duty Cycle Range Circuit
(continuous) Voltage
200
Invertec 208-230/
V350- 380-400/ 350A / 34V / 60% 80VDC
PIPE K1728-9 415-460/ AMPS
60/50 Hz 575 300A / 32V /100% 5-425
1& 3 Phase
60/50 Hz
Voltage
200
208
230
380
400
415
460
575
200
208
230
380
400
415
460
575
Phases
1
1
1
1
1
1
1
1
3
3
3
3
3
3
3
3
Input Amps
300Amps @
32Volts(100%)
Not
Recommended
76
69
Not
Recommended
Not
Recommended
41
36
31
41
39
36
23
22
22
19
16
Input Amps
350Amps @
34Volts(60%)
Not
Recommended
94
85
Not
Recommended
Not
Recommended
54
42
37
50
50
42
28
27
26
23
18
Line Cord
AWG
---
2
4
---
---
6
8
8
6
6
8
8
8
8
8
8
Maximum
Fuse size
---
125A
125A
---
---
80A
70A
50A
80A
80A
70A
50A
50A
50A
50A
35A
RECOMMENDED INPUT WIRE AND FUSE SIZES FOR MAXIMUM RATED OUTPUT
OUTPUT CABLES, CONNECTIONS AND LIMITATIONS
Recommended Fuse Sizes Base On The U.S. National Electrical Code And Maximum Machine Outputs
Input 50/60 Hz Recommended
Note 1. Not rated is indicated by 4-x ’ s in the box on the rating plate.
Note 2. When operating on these inputs, the line cord should be changed to an input conductor of 6 AWG or larger.
Select The output cable size based upon the following chart.
Cable sizes for Combined Length of Electrode and Work Cable (Copper) 75C rated:
DUTY CYCLE
100%
60%
CURRENT
300
350
LENGTH UP TO 200FT.(61m)
1/0
1/0
200-250 FT. (61-76m)
1/0
2/0
Notes
Note 1
Note 2
Note 2
Note 1
Note 1
Note 2
Note 2
Note 2
Height Width Depth Weight with Cord
Invertec
V350 PIPE 14.8 ” (373mm) 13.3 ” (338mm) 27.8 ” *(706mm*) 81.5 Lbs.(37 Kg)
PHYSICAL DIMENSIONS
* Overall Length Including Handle, 27.8” (706mm)
TEMPERATURE RANGES
STORAGE TEMPERATURE RANGE
-40 ° C to +40 ° C
OPERATING TEMPERATURE RANGE
-20 ° C to +40 ° C
