3. Location of Part/Components
Handle
Targeting Sight
Objective Lens
Horizontal Fine
Motion
Horizontal Clamp
LCD Display
Operating Keys
Tripod
Base Plate
Handle Screw
Center Mark &
Vertical Plate
Tubular Vial
Circular Vial
Battery Case
Eyepiece
Telescope Fine
Motion
Telescope Clamp
Tribrach
Locking Lever
Focusing Ring
Optical Plummet
Communication Port
Leveling Screw
