20 ©2011 Johnson Level & Tool
INITIAL SETTING
Initial Setting Instruction
The instrument has several settings for your option to meet different
requirements of measuring. After your purchase and before your
operation, do the initial setting for the instrument.
Item Setting
No.
1
2
3
4
5
Measuring mode for
Vertical Angle
Setting measuring
mode for vertical angle
Setting 0
vertical angle
Setting 1
zenith angle
6 Tilt sensor Set tilt function
Setting 0
OFF
Setting 1
ON
7 Data transmission
Set data transmission
function
Setting 0
OFF
Setting 1
ON
Automatic
Shut-off
Setting interval for
automatic shut-off
without an operation
Angle unit
Selecting angle display
unit DEG, GON, MIL
Setting
0
DEG
Setting
1
GON
Setting
2
MIL
Setting
3
DEG
Setting
0
OFF
Setting
1
10 min
Setting
2
20 min
Setting
3
30 min
Sound function
Confirming sound
every 90º
Setting 0
OFF
Setting 1
ON
Reading resolution
(minimal reading
display unit)
40-6932
40-6935
Setting 0
1”
2”
Setting 1
2”
5”
Item Description Parameter Setting
