Elitegroup NM70-I (V1.0) - Manual (Page 50)

Chapter 3
NM70-I USER MANUAL
46
When end-users encounter failure after attempting over-clocking, please take the
following steps to recover from it.
1. Shut down the computer.
2. Press and hold the “Page Up Key (PgUp)” of the keyboard, and then boot the PC
up.
3. Two seconds after the PC boots up, release the “Page Up Key (PgUp)”.
4. The BIOS returns to the default setting by itself.
Warning:
Over-clocking components can adversely affect the reliability of the system
and introduce errors into your system. Over-clocking can permanently
damage the motherboard by generating excess heat in components that are
run beyond the rated limits.
Fail-Safe Procedures for Over-clocking
Auto Detect DIMM/PCI Clk (Enabled)
When this item is enabled, BIOS will disable the clock signal of free DIMM/PCI slots.
Spread Spectrum (Enabled)
If you enable spread spetrum, it can significantly reduce the EMI (Electro-Magnetic
Interference) generated by the system.
Intel(R) Celeron(R) CPU 847 @ 1.10GHz
This is display-only field and displays the information of the CPU installed in your
computer.
Processor Speed (1100 MHz)
This item shows the CPU speed.
Memory Frequency (1067 MHz)
This item shows the memory frequency.
Total Memory (2048 MB (DDR3))
This item shows the total memory.
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
Tweak Menu
Auto Detect DIMM/PCI
Clock
Main Advanced Chipset Tweak Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
 : Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
ESC/Right Click: Exit
F4: Save & Exit

Tweak
Auto Detect DIMM/PCI Clk Enabled
Spread Spectrum Enabled
Intel(R) Celeron(R) CPU 847 @ 1.10GHz
Processor Speed
1100 MHz
Memory Frequency 1067 MHz
Total Memory
2048 MB (DDR3)
