Installing the System

2. Connecting Devices

No.

Components

No.

Components

1

LVDS1

6

HDD

2

CCD_DMIC

7

SYS_FAN

3

LVDSPW_CONN1

8

FRONT_LED

4

TOUCH_PANEL

9

MONO_OUT1

5

HDD_PWR

~

~
