Elitegroup V20 (V1.0) User Manual
Page 21
15
Installing the System
Table of Motherboard Components
LABEL
COMPONENTS
1. CPU Socket
Intel
®
Bay Trail-D platform
2. DC_IN connector
DC in connector
3. LAN
LAN connector
4. USB3 0_1~2
USB 3.0 connectors
5. FRONT_LED
Power LED header
6. MONO_OUT1
Internal Speakers Header
7. MIC
Microphone connector
8. HPOUT
Headphone out connector
9. F_USB3 0_1~2
Front panel USB 3.0 ports
10. SODIMM1
204-pin DDR3 SDRAM slot
11. CARD_READER
Card reader slot
12. SWITCH1~2
Brightness/Volume Up/Down buttons
13. PWR_SW
Power on/off button
14. LPC_DEBUG
LPC Debug header
15. MINI_PCIE
Mini card slot
16. MSATA
Mini card slot
17. LVDS1
LVDS connector
18. CCD_DMIC
Webcam header
19. LVDSPW_CONN1 LVDS power header
20. TOUCH_PANEL
Touch panel connector
21. HDD_PWR
HDD power connector
22. SYS_FAN
System cooling fan connector
23. HDD
SATA II connector
24. TXE_UNLOCK
TXE Unlock header with jumper
25. CLR_CMOS_HW1 Clear CMOS header with jumper
