The Rear
1.
2.
3.
4.
5.
6.
USB Ports
Your computer includes four Universal Serial Bus (USB) 2.0 ports. USB2.0 is the latest
development in Plug and Play technology.
It will eventually replace the need for separate connectors for external keyboards, serial ports,
and parallel (printer) port.
Audio Line Out
You can plug an external speaker, headphone or connect the line out jack to an audio device
such as a cassette recorder to record the notebook's audio output.
External Microphone Jack
This mono microphone jack is used to connect an external microphone.
PS/2 Connector
Allows you to connect any external PS/2 device such as mouse or keyboard.
Serial Port
This port is used to connect RS-232 serial devices to the Notebook. Three types of serial
devices are external mice, serial printers, and fax/modems.
Parallel Port
This port allows you to easily connect a parallel printer or plotter using this 25-pin bi-
directional female port.
