- 9 -
The LAN Port
This jack provides a standard RJ-45 connection for integration with an existing
network or a high-speed (DSL or cable) connection via a network cable.
When using a LAN, please use an EMI Shielding Cable to
minimize an inteference when transmitting.
The Modem Port
This jack is an internal 56K voice/fax/data modem. You will connect your computer
to your phone line through this port.
Always disconnect all telephone lines from the wall outlet
before servicing or disassembling this equipment. To reduce the risk of
fire use only No. 26 AWG or larger telecommunication line cord.
Microphone Jack
Allows you to receive monophonic input from an external microphone. Use of an
external microphone will disable the built-in microphone.
Headphone Jack
You can plug an external speaker, headphone or connect the line out jack to an
audio device such as a cassette recorder to record the Mobile PC's audio output.
