Chapter 3
Z87H3-A4 USER MANUAL
37
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Scroll to this item and press to view the following screen:
Smart Fan Function
CPU/System Fan 1/System Fan 2 Smart Fan Control (Enabled)
These items enable you to define the CPU/system fan 1/system fan 2 by smartly
adjusting the CPU/system fan 1/system fan 2 Fan. When it is set at certain tempera-
ture, the CPU/system fan 1/system fan 2 PWM value will change accordingly.
Main Advanced Chipset M.I.B. III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Temperature (DTS) : 49
System Temperature : 29 O C
CPU Fan Speed : 2884 RPM
System Fan 1 Speed : 0 RPM
System Fan 2 Speed : 0 RPM
CPU Voltage : 1.788V
DIMM Voltage : 1.500V
+12V : 12.096V
+5V : 4.224V
+3.3V : 3.372V
PCH Voltage : 1.056V
TCC Activation Temperature (DTS) 100
Smart Fan Function
PC Health Status
Enable CPU SmartFan
Main Advanced Chipset M.I.B. III Boot Security Exit
CPU Smart Fan Control Enabled
Smart Fan Mode Normal
Smart Fan start PWM value 180
Smart Fan start PWM TEMP(DTS)
70
DeltaT +3
Smart Fan Slope PWM value 10 PWM value/unit
CPU Fan Full Speed Offset (DTS) 77
System Fan 1 Smart Fan Control Enabled
Smart Fan Mode Normal
Smart Fan start PWM value 180
Smart Fan start PWM TEMP(DTS)
70
DeltaT +3
Smart Fan Slope PWM value 10 PWM value/unit
System Fan 1 Full Speed Offset (DTS) 77
System Fan 2 Smart Fan Control Enabled
Smart Fan Mode Normal
Smart Fan start PWM value 180
Smart Fan start PWM TEMP(DTS)
70
DeltaT +3
Smart Fan Slope PWM value 10 PWM value/unit
System Fan 2 Full Speed Offset (DTS) 77
+/- : Change Opt.
Enter/Dbl Click : Select
lk
mn
: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
