Using BIOS
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
CPU/System Smart FAN Control (Enabled)
This item allows you to enable/disable the control of the CPU/system fan speed by
chang-ing the fan voltage.
Smart Fan Function
Scroll to this item and press to view the following screen:
CPU Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
SMART Fan start PWM value 56
SMART Fan start PWM TEMP 27
Delta T +3
SMART Fan Slope PWM value 6 PWM value/unite
CPU Fan Full Speed Offset (-) 60
System Smart Fan Control [Enabled]
Smart Fan Mode [Normal]
SMART Fan start PWM value 56
SMART Fan start PWM TEMP 27
Delta T +3
SMART Fan Slope PWM value 6 PWM value/unite
System Fan Full Speed Offset (-) 60
