Orion/MPV-10K Adjustment & Maintenance Manual
16
2.14 ORION-3A Valve Assembly (55287) Parts List
The following table lists the component parts of the ORION-3A.
Ref
Number
PN
Description
Quantity
1
57482
Nut,Valve Needle Housing
2
2
54401
Locknut
2
3
58079
Knob
2
4
57889
Knob, Insert
2
5
57256
Gear, Spur 40 Teeth
2
6
59233
Gear, Spur 18 Teeth
2
7
55896
Valve Seat
4
8
59387
Valve Seat, Stem
4
9
59045
Valve, Needle Seat
4
10
54540
Housing, Valve Needle
2
11
59551
Valve Needle
2
12
57600
Bushing, End
1
13
58554
Cap, End
1
14
58699
Shaft
1
15
58597
Piston
1
16
59309
Body, Dual Valve
1
17
57580
Knob
1
18
55533
Valve Needle
2
19
55159
Housing, Valve Needle
2
20
56784
Locknut, 9/16-18UNF-3A, SST
1
21
58464
Setscrew, 12-24NC x 1/4, SST
14
22
58308
Ball, Tungsten carbide
14
23
59383
Setscrew, 6-32NCx1/8 SST
4
24
58342
Screw, Cap Hex Socket Head, #2-56UNC-3A
6
25
59322
Setscrew, 6-32NCx1/4 SST
6
26
59326
Setscrew, 2-56NCx1/8, alloy steel
4
27
55569
O-ring, Fluorocarbon (Viton) color black w/white dot
5
28
55552
O-ring, Fluorocarbon (Viton) color black w/white dot
4
29
58090
O-ring, Fluorocarbon (Viton) color black w/white dot
1
30
60633
Retainer, Packing Backup
4
31
55570
Washer, Backing
4
32
58045
O-ring, Fluorocarbon (Viton) color black w/white dot
1
33
59245
Washer, Nylon
2
34
60202
Setscrew, hex
2
35
60837
Screw, MACH Pan Head #10- 32NFx1/2 Phillips Head 300 Series SST
2
36
54905
Screw, Self Sealing
1
38
57027
Washer, backup
1
39
54448
Retainer, Packing backup
1
Table 2-3. ORION-3A Valve Assembly Parts List
