10 Orion/MPV-10K Adjustment & Maintenance Manual
2.12 ORION-2C Valve Assembly (55283) Parts List
The following table lists the component parts of the ORION-2C.
Ref
Number PN Description Quantity
1 57482 Nut,Valve Needle Housing 2
2 54401 Locknut 2
3 58079 Knob 2
4 57889 Knob,Insert 2
5 57256 Gear,Spur 40 Teeth 2
6 59233 Gear,Spur 18-tooth 2
7 55896 Valve Seat 4
8 59387 Valve Seat,Stem 4
9 59045 Valve,Needle Seat 4
10 54540 Housing,Valve Needle 2
11 59551 Valve Needle 2
12 57906 Bushing,End 1
13 59378 Cap,End 1
14 59495 Shaft 1
15 59241 Piston 1
16 55714 Body,Dual Valve 1
17 57580 Knob 1
18 55533 Valve Needle 2
19 55159 Housing,Valve Needle 2
20 56784 Locknut 1
21 59845 Plug,Expansion 14
23 59383 Setscrew,6-32NCx1/8 SST 4
24 58342 Screw,Cap Hex Socket Head, #2-56UNC-3A 6
25 59322 Setscrew,6-32NCx1/4 SST 6
26 59326 Setscrew,2-56NCx1/8, alloy steel 4
27 55554 O-ring, Buna N (Nitrile) 70 Durometer Color Black 5
28 55536 O-ring, Buna N (Nitrile) 70 Durometer Color Black 4
29 55573 O-ring, Buna N (Nitrile) 70 Durometer Color Black 1
30 60633 Retainer, Packing Backup 4
31 55570 Washer, Backing .04 Thick 4
32 55577 O-ring, Buna N (Nitrile) 70 Durometer Color Black 1
33 59245 Washer,#8 Screw Size .187, ID x .440 OD x .040 Thick Nylon 2
34 60202 Setscrew, hex 2
35 60837 Screw, MACH Pan Head 2
36 58976 Screw,Self Sealing 1
38 53308 Label 1
41 59878 Spacer .005 thk Mylar 2
42 59880 Spacer .007 thk Mylar 2
Table 2-1. ORION-2C Valve Assembly Parts List
