Installation Instructions 44-2303
3
Revised Feb‐14
Bill of Materials
Put the vehicle on level ground and measure the gap between all of the
tires and the fenders.
1. Lift the vehicle and remove the wheels. 2.
Disconnect the ABS line from the fender liner and unplug.
Disconnect the ABS line from the other two clips as well. 3. Unbolt the brake calipers and hang out of the way. 4.
The Bill of Materials represents the component contents of this kit. All hardware is of the highest grade
and the components are manufactured to exacting specifications for a trouble free installation. Use the
attached torque specifications chart when final tightening of the nut and bolts are done.
DESCRIPTION QTY
Lower Control Arms w/ Uniball 2
Lower Control Arm Bushings 8
LCA Inner Sleeve 3.944x.725 ID 2
LCA Inner Sleeve 4.535x.725 ID 2
LCA Adapter Pin 2
LCA Upper Mis Spacer 2
LCA Lower Mis Spacer 2
DESCRIPTION QTY
Hex Bolt - M20 x 2.5 - 110mm 2
M20 AN Flat Washer 4
M20 x 2.5 Nyloc® 2
9/16"-18 Stover Nut 4
9/16 G8 Flat Washer 2
9/16" AN Washer 2
1/2-20 x .500 Long Button Head 2
9/16-18 STD Nut 2
To use the factory Sway Bar you must purchase Kit # 67-2999.
